凯斯零件查询(LB424S XL) - BALER (11/16-) (31.220.100) - MAIN GEARBOX, ARM SHAFT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
416 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47361020
|
[2] |
SEALING RING
|
ZED
|
| 2. |
84346536
|
[2] |
TAPERED BEARING,140mm ID x 210mm OD x 53mm W
|
ZED
|
| 3. |
84394455
|
[1] |
SPACER
|
ZED
, Serial Range: -C071 Superseded by part number: 47492604
|
| 3. |
47492604
|
[1] |
SPACER
|
ZED
, Start Serial: D072
|
| 4. |
84346518
|
[1] |
GEAR
|
ZED
, Serial Range: -C144
|
| 4. |
47706737
|
[1] |
GEAR
|
ZED
, Start Serial: D145
|
| 5. |
47360992
|
[1] |
SHAFT
|
ZED
, Serial Range: -C071
|
| 5. |
47492599
|
[1] |
SHAFT
|
ZED
, Serial Range: -F072144
|
| 5. |
47706738
|
[1] |
CRANKSHAFT
|
ZED
, Start Serial: D145
|
| 6. |
84074501
|
[1] |
SET OF RINGS
|
ZED
|
| 7. |
47361001
|
[2] |
COVER
|
ZED
|
| 8. |
87688225
|
[2] |
O-RING,209.1mm ID x 3.53mm Width
|
ZED
|
| 9. |
412123
|
[16] |
LOCK WASHER,13.1mm ID x 21.1mm OD x 2.55mm Thk
|
NH
|
| 10. |
87012129
|
[16] |
BOLT,Hex, M12 x 40, 10.9, Full Thd
|
RAC
, Serial Range: -C144
|
| 10. |
87022684
|
[16] |
BOLT,Hex, M12 x 45mm, Cl 10.9
|
GI
, Start Serial: D145
|
| 11. |
47492680
|
[1] |
SPACER
|
ZED
, Start Serial: D072
|
