| . . | 24100J5029F6 | [1] | CONTROL ASSY | |
| 2. | 2419T3612 | [1] | PIN | PIN |
| 3. | 24100N2814F2 | [1] | LEVER ASSY, CONTROL | LEVER ASSY, CONTROL |
| 3-5. | 2406P2495D1 | [1] | LEVER, CONTROL | LEVER, CONTROL |
| 3-4. | 2406P2495D2 | [1] | LEVER, CONTROL | LEVER, CONTROL |
| 3-5. | 2406P2496D1 | [1] | PEDAL | KOB |
| 3-6. | 2406P2496D2 | [1] | PEDAL | KOB |
| 3-7. | 4019T12 | [1] | PIN | KOB |
| 3-8. | 4016P16 | [1] | BRACKET | KOB |
| 3-9. | 4018T20 | [2] | SPACER | KOB |
| 3-10. | 4025Z8 | [4] | NEEDLE BEARING | KOB |
| 3-11. | 4045Z8 | [4] | OIL SEAL | KOB |
| 3-13. | 6Z1 | [2] | LEVER | KOB |
| 3-13. | 3611V012 | [1] | WASHER | KOB |
| 3-14. | ZP15D05065 | [1] | COTTER PIN | KOB |
| 3-15. | ZS16C10025 | [4] | SCREW | KOBM10x1.50x25mm Superseded by part number: ZS18C10025 |
| 3-16. | ZW26X10000 | [8] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 3-17. | ZS16C10038 | [4] | CAPSCREW | |
| 3-18. | 2406T1678D1 | [1] | LINK | KOB |
| 3-19. | 2406T1678D2 | [1] | LINK | KOB |
| 4. | 2418T10657 | [2] | PLATE | |
| 5. | 2405U101D1208 | [6] | BUSHING | KOB |
| 6. | 2406T1670 | [2] | LEVER | KOB |
| 7. | 2406T1675 | [4] | LINK | KOB |
| 11. | 2406T1672 | [4] | YOKE | KOB Superseded by part number: 2406T2278 |
| 13. | ZW16X08000 | [4] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 15. | 2419R9D4 | [8] | COTTER PIN | KOBSnap -- OD 12mm x 35.8mm Long |
| 16. | ZW16X12000 | [8] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 17. | ZN16C06005 | [4] | NUT | KOBM06x1.0mm Superseded by part number: ZN18C06005 |
| 19. | ZM11C10030 | [4] | SCREW | KOBM10x1.50x30mm (Incls. Lockwasher) |
| 21. | ZM11C10025 | [8] | BOLT | KOBM10x1.50x25mm (Incls. Lockwasher) Superseded by part number: ZM12C10025 |
| 24. | ZN16C16010 | [2] | NUT | KOB |
| 25. | ZW16X16000 | [1] | WASHER | KOBID 16 x OD 30 x Th 3.2mm |
| 26. | 2417R63 | [1] | SPRING | KOBGAS |
| 27. | 2416Z312D17 | [2] | SHEET, RUBBER | SHEET, RUBBER |
| 28. | ZP15K02020 | [2] | SPLIT PIN | KOB |
| 29. | 24100N2792F1 | [1] | SUPPORT ASSY | SUPPORT ASSY |
| 29-1. | 2416P7220 | [1] | SUPPORT | SUPPORT |
| 29-2. | 2414P2906 | [1] | COVER | KOB |
| 29-3. | 2414T1973 | [1] | COVER | COVER |
| 29-4. | ZS31C05014 | [6] | SCREW,Phillips Drive, Pan HD, M5 x 14mm | KOBM05x0.8x14mm |
| 29-5. | ZW11P05000 | [6] | WASHER | KOB Superseded by part number: ZW16P05000 |
| 30. | ZS18C08014 | [4] | SCREW,Hex, M8 x 14mm | KOBM08x1.25x14mm |
| 31. | ZW22X08000 | [4] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 37. | 2420Z699 | [5] | GROMMET | KOB |
| 43. | 2422P583 | [1] | FRAME, UPP | |
| 43-1. | ZN11C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 44. | 2419T3603 | [1] | PIN SHAFT | PIN SHAFT |
| 46. | 2416P7247 | [1] | SUPPORT | SUPPORT |
| 47. | 2418T5373C2 | [4] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 48. | ZS13C16100 | [6] | SCREW | KOBM16x2.0x100mm |
| 49. | 2419R9D2 | [2] | COTTER PIN | KOBOD 08mm x 27.7mm Long |
| 51. | ZM11C08020 | [2] | BOLT | KOBM08x1.25x20mm (Incls. Lockwasher) Superseded by part number: ZM12C08020 |
| 53. | 2422P595 | [1] | FRAME, UPPER | |
| 54. | 2486R71 | [1] | CABLE | KOB |
| 55. | 2432T1806 | [1] | LABEL | LABEL |
| 56. | 2406R223D1 | [1] | FLEXIBLE CONTROL | KOBCABLE |
| 57. | 2406R223D3 | [1] | FLEXIBLE CONTROL | KOB |
| 62. | 2444Z2256 | [1] | HOSE | HOSE |
| 63. | 2444Z2255 | [2] | CONNECTOR | CONNECTOR |
| 64. | ZC15X05000 | [2] | CLIP | KOB |
| 65. | 2416T11050 | [1] | BRACKET | |
| 66. | ZS18C08025 | [2] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 67. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 69. | 2416T11051 | [1] | BRACKET | BRACKET |
| 72. | 2416Z253 | [4] | RUBBER SLEEVE | KOBCUSHION |
| 73. | 2414T1054 | [4] | COVER | KOB |
| 74. | 2418T9226D1 | [2] | SPACER | KOB |
| 75. | ZN32C16015 | [2] | NUT | KOBM16x2.0mm |
| 76. | R16T0152D2 | [4] | WASHER | KOBFlat -- ID 17 x OD 30 x Th 3.2mm |
| 77. | 2416P7315 | [1] | STAND, SEAT | |
| 79. | 2427R457 | [1] | MAT, FLOOR | MAT, FLOOR |
| 81. | 2427R459 | [1] | MAT, FLOOR | MAT, FLOOR |
| 82. | 2416P8514 | [1] | SUPPORT | KOB |
| 83. | 2479Z932 | [1] | SWITCH | KOBLIMIT |
| 84. | 2414Z265 | [1] | COVER | KOB |
| 85. | ZS31C04030 | [2] | SCREW,Phillips Drive, Pan HD, M4 x 30mm | KOBM04x0.7x30mm |
| 86. | ZN16C04003 | [2] | NUT | KOBM04x0.7mm Superseded by part number: ZN18C04003 |
| 87. | ZW16K04000 | [4] | WASHER | KOBID 04 x OD 08 x Th 0.8mm |
| 88. | 2448U230F1 | [1] | SEAT OPERATORS SEE FIG:02-014 | SEAT OPERATORS SEE FIG:02-014 |
| 89. | 2416N3192 | [1] | SUPPORT | SUPPORT |
| 90. | 24100N2790F3 | [1] | SUPPORT ASSY | |
| 90-2. | 2414P2905 | [1] | COVER | KOB(L H) |
| 90-3. | 2414T1974 | [1] | COVER (L H) | |
| 90-5. | 2416Z332 | [1] | SHEET | KOB |
| 90-6. | 2417Z252 | [1] | SPRING | KOB |
| 90-8. | ZR36X00600 | [1] | SNAP RING | KOBE-Ring -- Shaft 06mm x OD 12mm |
| 90-9. | ZS31C05014 | [8] | SCREW,Phillips Drive, Pan HD, M5 x 14mm | KOBM05x0.8x14mm |
| 90-10. | ZW11P05000 | [8] | WASHER | KOB Superseded by part number: ZW16P05000 |
| 90-12. | 2406Z294D3 | [1] | GRIP | KOB |
| 90-16. | 2405U101D1612 | [2] | BUSHING | KOB |
| 90-18. | 2432T1818 | [1] | CLAMP | CLAMP |
| 90-19. | ZS18C08016 | [2] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| 90-20. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 90-21. | 2416T11070 | [1] | SEAT, RUBBER | SEAT, RUBBER |
| 90-22. | 2416N3193 | [1] | SUPPORT (LH) | |
| 90-23. | 2406P2544 | [1] | LEVER | KOB |
| 91. | 24100J4972F3 | [1] | REMOTE-CONTROL ASSY | |
| 92. | 2422N802 | [1] | PLATE FLOOR | |
| 93. | 2427P1827 | [1] | MAT, FLOOR | |
| 94. | 2427P1828 | [1] | MAT, FLOOR | |
| 95. | 2419T3784D2 | [2] | PIN | KOB |
| 96. | 2419T3790D1 | [2] | PIN | KOB |
| 97. | 2419T3784D1 | [6] | PIN | KOB |
