现代零件查询R36N-7 SWING POSTEPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
360 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
XJDH-03618
|
[1] |
SWING POST
|
|
| 2. |
XJDH-03619
|
[1] |
PIN
|
|
| 3. |
XJDH-01148
|
[1] |
COLLAR-POST PIN
|
|
| 4. |
XJDH-01149
|
[1] |
WASHER
|
|
| 5. |
XJDH-00085
|
[1] |
BOLT
|
|
| 6. |
XJDH-01516
|
[1] |
PIN
|
|
| 7. |
XJDH-01181
|
[1] |
COLLAR
|
|
| 8. |
XJDH-00070
|
[1] |
BOLT
|
|
| 9. |
XJDH-00280
|
[1] |
WASHER
|
|
| 10. |
XJDH-01514
|
[2] |
PIN
|
|
| 11. |
XJDH-01181
|
[2] |
COLLAR
|
|
| 12. |
XJDH-00070
|
[2] |
BOLT
|
|
| 13. |
XJDH-00280
|
[2] |
WASHER
|
|
| 14. |
XJDH-01192
|
[AR] |
SHIM(A, 0.5T)
|
|
| 15. |
XJDH-01193
|
[AR] |
SHIM(B, 1.0T)
|
|
| 16. |
XJDH-01194
|
[AR] |
SHIM(C, 0.5T)
|
|
| 17. |
XJDH-01195
|
[AR] |
SHIM(D, 1.0T)
|
|
| 18. |
XJDH-01196
|
[AR] |
SHIM(E, 0.5T)
|
|
| 19. |
XJDH-01197
|
[AR] |
SHIM(F, 1.0T)
|
|
