凯斯零件查询(LB424S XL) - BALER (11/16-) (35.570.045) - STANDARD AND PARTIAL BALE EJECTION MECHANISM, CYLINDER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
968 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47470677
|
[1] |
HYDRAULIC CYLINDER
|
ZED
Incl 17
|
| 2. |
84591579
|
[1] |
SHAFT
|
ZED
|
| 3. |
47658869
|
[2] |
PLATE
|
ZED
|
| 4. |
338949
|
[2] |
CARRIAGE BOLT,M10 x 1.5 x 25mm, Cl 8.8
|
NH
|
| 5. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 6. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 7. |
47968807
|
[1] |
SLEEVE
|
ZED
|
| 8. |
47974621
|
[1] |
SLEEVE
|
ZED
|
| 9. |
87491174
|
[1] |
SHAFT
|
ZED
|
| 10. |
378247
|
[2] |
WASHER,21mm ID x 39mm OD x 3mm Thk
|
ZED
|
| 11. |
370024
|
[2] |
CIRCLIP,M20, Ext
|
NH
|
| 12. |
47974813
|
[1] |
SHAFT
|
ZED
|
| 13. |
84571865
|
[2] |
SPACER,25mm ID x 35mm OD x 16mm L
|
ZED
|
| 14. |
47958853
|
[1] |
HYDRAULIC CYLINDER
|
ZED
Incl 18
|
| 15. |
370002
|
[4] |
CIRCLIP,M25, External
|
NH
|
| 16. |
47819718
|
[1] |
SHAFT
|
ZED
|
| 17. |
47666739
|
[1] |
SEAL KIT
|
ZED
|
| 18. |
84154203
|
[1] |
SEAL KIT
|
ZED
|
