| . . | 24100J6049F2 | [1] | ARM ASSY 3.0 M(SUPER LONG) (9 FT-10 IN) | |
| 2. | 2438U897F1 | [1] | CYLINDER | KOB |
| 3. | 2406N772F1 | [1] | LINK, BUCKET | LINK, BUCKET |
| 3-6. | 2405T825 | [2] | BUSHING | KOBID 65 x OD 80 x 60mm Long |
| 3-7. | 2405T824 | [2] | BUSHING | KOBID 60 x OD 75 x 69mm Long |
| 4. | 2406P2541D1 | [1] | LINK CONROD | KOB |
| 5. | 2406P2541D2 | [1] | LINK CONROD | KOB |
| 6. | 2419P1643 | [2] | PIN | KOB |
| 7. | 2419P1683D1 | [2] | PIN | KOB Superseded by part number: LQ12B01205P1 |
| 8. | 2419P1556D4 | [1] | PIN | KOB |
| 9. | 2419P1557D1 | [1] | PIN | KOB Superseded by part number: 2419P3395D1 |
| 10. | 2418P10045 | [1] | TUBE | KOB |
| 11. | 2418P10046 | [1] | RIGID TUBE | KOB295mm Long (11-39/64 in) |
| 12. | 2418T12307 | [2] | TUBE | KOB |
| 13. | 2432T1333 | [2] | CLAMP | KOBSingle Block -- 50x30x25mm Superseded by part number: YW43H01049P1 |
| 14. | 2445R138D3 | [6] | SEAL,60mm ID x 75mm OD x 4mm Thk | KOBDust -- ID 60 x OD 75 x Th 4mm |
| 15. | 2445R138D6 | [2] | SEAL,70mm ID x 85.3mm OD x 4mm Thk | KOBSeal, Dust -- ID 70 x OD 85 x Th 4mm |
| 16. | 2445R220D2 | [4] | SEAL,65mm ID x 80mm OD x 5mm Thk | KOBDust -- ID 65 x OD 80 x Th 5mm Superseded by part number: 84499663 |
| 17. | ZX58N10140 | [2] | FLEXIBLE HOSE,25.40 mm ID x 1400.00 mm | KOBHOSE |
| 18. | ZX58N10070 | [2] | FLEXIBLE HOSE | KOB700mm Long (27-1/2 in) |
| 19. | ZG91S02000 | [5] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 20. | ZG91U02000 | [2] | LUBE NIPPLE | KOB90° x 1/8" PT |
| 21. | ZS13C14120 | [4] | SCREW | KOBM14x2.0x120mm Superseded by part number: ZS18C14120 |
| 22. | ZS13C10045 | [6] | SCREW | KOBM10x1.50x45mm Superseded by part number: ZS18C10045 |
| 23. | ZN12C14011 | [8] | NUT | KOBM14x2.0mm Superseded by part number: ZN18C14011 |
| 24. | ZW22X10000 | [14] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 25. | ZC26X22011 | [4] | CLAMP | KOBSingle Line -- 38x29x65mm Long |
| 26. | ZC45X11009 | [2] | CLIP | KOBClamp, Single Line -- ID 11x35.5mm Long Superseded by part number: ZC46X11009 |
| 27. | 2411J1795F1 | [1] | ARM | |
| 27-21. | 2405P472 | [2] | BUSHING | KOBID 65 x OD 80 x 75mm Long, Flange OD 130 |
| 27-22. | 2405T823 | [2] | BUSHING | KOBID 70 x OD 85 x 70mm Long |
| 27-23. | 2405T824 | [2] | BUSHING | KOBID 60 x OD 75 x 69mm Long |
| 27-24. | 2418T10839 | [1] | SPACER | KOB |
| 27-25. | 2418T10838 | [1] | SPACER | KOB |
| 28. | ZW22X08000 | [2] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 29. | ZS13C08012 | [2] | SCREW | KOBM08x1.25x12mm Superseded by part number: ZS18C08012 |
| 31. | 2420R349D170 | [1] | FLEXIBLE HOSE | KOB1700mm Long (66-59/64 in) Superseded by part number: HX21E04170DX |
| 32. | ZH22Z04000 | [1] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 33. | ZH32Z04002 | [1] | ELBOW | KOB90° -- 1/4" PF - 1/8" PT |
| 35. | ZS13C10060 | [8] | SCREW | KOBM10x1.50x60mm Superseded by part number: ZS18C10060 |
| 36. | ZD12P02600 | [2] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 37. | ZS13C12130 | [2] | SCREW | KOBM12x1.75x130mm Superseded by part number: ZS18C12130 |
| 38. | ZN12C12010 | [4] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
