| . . | 24100N2941F1 | [1] | ARM ASSY 2.1 M(6 FT-11 IN) | |
| 1. | 2411J1753F1 | [1] | ARM | KOB |
| 1-16. | 2405P472 | [2] | BUSHING | KOBID 65 x OD 80 x 75mm Long, Flange OD 130 |
| 1-17. | 2405T823 | [2] | BUSHING | KOBID 70 x OD 85 x 70mm Long |
| 1-18. | 2405T824 | [2] | BUSHING | KOBID 60 x OD 75 x 69mm Long |
| 1-19. | 2418T10839 | [1] | SPACER | KOB |
| 1-20. | 2418T10838 | [1] | SPACER | KOB |
| 2. | 2438U897F1 | [1] | CYLINDER | KOB |
| 3. | 2406N772F1 | [1] | LINK, BUCKET | LINK, BUCKET |
| 3-6. | 2405T825 | [2] | BUSHING | KOBID 65 x OD 80 x 60mm Long |
| 3-7. | 2405T824 | [2] | BUSHING | KOBID 60 x OD 75 x 69mm Long |
| 4. | 2406P2541D1 | [1] | LINK CONROD | KOB |
| 5. | 2406P2541D2 | [1] | LINK CONROD | KOB |
| 6. | 2419P1643 | [2] | PIN | KOB |
| 7. | 2419P1683D1 | [2] | PIN | KOB Superseded by part number: LQ12B01205P1 |
| 8. | 2419P1556D4 | [1] | PIN | KOB |
| 9. | 2419P1557D1 | [1] | PIN | KOB Superseded by part number: 2419P3395D1 |
| 10. | ZX58N10100 | [2] | FLEXIBLE HOSE | KOB1000mm Long (39-3/8 in) |
| 11. | 2445R138D3 | [6] | SEAL,60mm ID x 75mm OD x 4mm Thk | KOBDust -- ID 60 x OD 75 x Th 4mm |
| 12. | 2445R138D6 | [2] | SEAL,70mm ID x 85.3mm OD x 4mm Thk | KOBSeal, Dust -- ID 70 x OD 85 x Th 4mm |
| 13. | 2445R220D2 | [4] | SEAL,65mm ID x 80mm OD x 5mm Thk | KOBDust -- ID 65 x OD 80 x Th 5mm Superseded by part number: 84499663 |
| 14. | ZD12P02600 | [2] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 15. | ZS13C10060 | [8] | SCREW | KOBM10x1.50x60mm Superseded by part number: ZS18C10060 |
| 16. | ZS13C12130 | [2] | SCREW | KOBM12x1.75x130mm Superseded by part number: ZS18C12130 |
| 17. | ZS13C14120 | [4] | SCREW | KOBM14x2.0x120mm Superseded by part number: ZS18C14120 |
| 18. | ZW22X10000 | [10] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 19. | 2418P10046 | [1] | RIGID TUBE | KOB295mm Long (11-39/64 in) |
| 20. | 2418P10045 | [1] | TUBE | KOB |
| 21. | ZG91S02000 | [5] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 22. | ZG91U02000 | [2] | LUBE NIPPLE | KOB90° x 1/8" PT |
| 23. | ZN12C12010 | [4] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 24. | ZN12C14011 | [8] | NUT | KOBM14x2.0mm Superseded by part number: ZN18C14011 |
| 25. | 2432T1333 | [2] | CLAMP | KOBSingle Block -- 50x30x25mm Superseded by part number: YW43H01049P1 |
| 25. | ZS13C10045 | [2] | SCREW | KOBM10x1.50x45mm Superseded by part number: ZS18C10045 |
