| . . | 24100J6035F3 | [1] | BOOM ASSY,4.6 M (15 F 1 INCH), Serial Range: LP1601-LP1720 | |
| . . | 24100J6035F4 | [1] | BOOM ASSY YP0301- to | |
| 3. | 2438U929F1 | [1] | ARM | KOB, Serial Range: LP1601-LP1690 |
| 4. | 2418T12262 | [1] | TUBE, Serial Range: LP1601-LP1720 | TUBE, Serial Range: LP1601-LP1720 |
| 3. | 2438U929F2 | [1] | HYDRAULIC CYLINDER | KOBCYLINDER YP0301- to |
| 5. | 2418T12263 | [1] | RIGID TUBE | KOB |
| 6. | 2418T12264 | [1] | TUBE, Serial Range: LP1601-LP1720 | TUBE, Serial Range: LP1601-LP1720 |
| 13. | 2418P10041 | [1] | RIGID TUBE | KOB |
| 14. | ZX28N12080 | [1] | HOSE ASSY. | KOB |
| 15. | ZX28N10080 | [5] | FLEXIBLE HOSE | KOBHOSE, Serial Range: LP1601-LP1720 Superseded by part number: 2444R1169D2 |
| 16. | 2420R349D276 | [1] | HYDRAULIC HOSE | KOBHOSE Superseded by part number: HX21E04280DX |
| 18. | ZG91S02000 | [3] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight, Serial Range: YP0301-YP0467 |
| 20. | 2419P1654 | [1] | PIN | KOB Superseded by part number: 2419P1693 |
| 23. | 2419P1557D1 | [1] | PIN | KOB Superseded by part number: 2419P3395D1 |
| 25. | 2445R138D6 | [2] | SEAL,70mm ID x 85.3mm OD x 4mm Thk | KOBSeal, Dust -- ID 70 x OD 85 x Th 4mm |
| 26. | ZH22Z04000 | [6] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 19. | ZG91U02000 | [5] | LUBE NIPPLE | KOB90° x 1/8" PT, Serial Range: YP0301-YP0467 |
| 31. | ZC26X22011 | [4] | CLAMP | KOBSingle Line -- 38x29x65mm Long |
| 32. | 2432T2244 | [5] | CLAMP | KOBDouble -- 102x32x12mm (Ø23xØ23mm) |
| 33. | 2432T2242 | [3] | CLAMP | KOBDouble -- 106x38x12mm (Ø23xØ29mm) |
| 34. | 2416T3655 | [2] | CLAMP | KOB |
| 35. | ZD12P02600 | [6] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 36. | ZS13C14130 | [5] | SCREW | KOBM14x2.0x130mm |
| 37. | ZS13C12130 | [1] | SCREW | KOBM12x1.75x130mm Superseded by part number: ZS18C12130 |
| 38. | ZS13C12045 | [3] | SCREW | KOBM12x1.75x45mm Superseded by part number: ZS18C12045 |
| 39. | ZS23C10070 | [4] | SCREW,Hex Socket Head, M10 x 70mm | KOBM10x1.50x70mm Superseded by part number: ZS28C10070 |
| 40. | ZS23C10060 | [20] | SCREW,Hex Socket Head, M10 x 60mm | KOBM10x1.50x60mm |
| 41. | ZS13C10045 | [5] | SCREW | KOBM10x1.50x45mm Superseded by part number: ZS18C10045 |
| 42. | ZS13C10040 | [3] | SCREW | KOBM10x1.50x40mm Superseded by part number: ZS18C10040 |
| 43. | ZN12C14011 | [10] | NUT | KOBM14x2.0mm Superseded by part number: ZN18C14011 |
| 44. | ZN12C12010 | [2] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 45. | ZN11C06005 | [5] | NUT | KOBNUT M06x1.0mm Superseded by part number: ZN18C06005 |
| 46. | ZW22X12000 | [5] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 47. | ZW22X10000 | [11] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 48. | ZW22X06000 | [5] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 49. | ZS13C10050 | [2] | SCREW | KOBM10x1.50x50mm Superseded by part number: ZS18C10050 |
| 50. | ZN12C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 51. | ZW11X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm Superseded by part number: ZW16X10000 |
| 52. | ZW11X06000 | [5] | WASHER | KOBID 06.6 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 53. | 2432T1333 | [1] | CLAMP | KOBSingle Block -- 50x30x25mm Superseded by part number: YW43H01049P1 |
| 54. | ZW22K10000 | [24] | LOCK WASHER | KOBLock -- ID 10.2 x OD 15.7 x Th 2.5mm |
| 55. | ZC45X11009 | [1] | CLIP | KOBClamp, Single Line -- ID 11x35.5mm Long Superseded by part number: ZC46X11009 |
| 58. | 2444R870D12 | [1] | FLEXIBLE HOSE | KOB, Serial Range: LP1601-LP1720 |
| 59. | ZX28N10090 | [3] | FLEXIBLE HOSE | KOB, Serial Range: LP1601-LP1720 |
| 64. | 2419T3846 | [1] | PIN | KOB Superseded by part number: 2419T6431 |
| 65. | 2418T12645 | [1] | PLATE | KOB125 x 420 x Th 9.0mm |
| 66. | ZS13C12030 | [2] | CAPSCREW | KOBSCREW M12x1.75x30mm Superseded by part number: ZS18C12030 |
| 67. | 2411J1792F1 | [1] | BOOM, Serial Range: LP1601-LP1720 | |
| 67-33. | 2405T846 | [2] | BUSHING | KOB |
| 68. | 2418P11965D1 | [1] | TUBE | KOB |
| 69. | 2418P11965D2 | [1] | TUBE | KOB |
| 70. | 2418P11966D1 | [1] | TUBE | KOB |
| 71. | 2418P11966D2 | [1] | TUBE | KOB |
| 72. | 2418P11967D2 | [1] | TUBE, Serial Range: LP1601-LP1720 | TUBE, Serial Range: LP1601-LP1720 |
| 73. | 2418T12674 | [2] | TUBE | KOB |
| 74. | 2418P11967D1 | [1] | TUBE, Serial Range: LP1601-LP1720 | TUBE, Serial Range: LP1601-LP1720 |
| 75. | 2420R349D7 | [2] | HOSE | KOBHOSE Superseded by part number: 2420R349D200 |
| 76. | ZA23B22000 | [2] | HYD CONNECTOR | KOBM30x1.50x38mm Long |
| 77. | 2419P1671D1 | [1] | PIN | KOB Superseded by part number: 2419P1699D1 |
| 78. | 2419P1685D1 | [2] | PIN | KOB Superseded by part number: 2419P1694D1 |
| 79. | B16T0442D10 | [2] | SHIM,140mm OD x 77mm ID x 1.2mm Thk | KOBID 77 x OD 140 x Th 1.2mm |
| 80. | B16T0442D11 | [2] | SHIM,140mm OD x 77mm ID x 1.6mm Thk | KOBID 77 x OD 140 x Th 1.6mm |
| 81. | B16T0442D12 | [2] | SHIM,140mm OD x 77mm ID x 2.3mm Thk | KOBID 77 x OD 140 x Th 2.3mm |
| 82. | 2418T12675D1 | [2] | COLLAR CLAMP | KOB |
| 83. | 2438U922F1 | [1] | CYLINDER | KOB Superseded by part number: 2438U923F1 |
| 84. | 2438U923F1 | [1] | CYLINDER | KOB |
| 85. | 2416T13056 | [1] | BRACKET | KOB |
| 86. | ZS13C10018 | [1] | SCREW | KOBM10x1.50x18mm |
| 87-33. | 2405T846 | [2] | BUSHING | KOB |
| 87. | 2411J2747F1 | [1] | BOOM | KOBYP0301- to |
| 88. | 2418T17312 | [1] | TUBE | KOBYP0301- to |
| 89. | 2418T17313 | [1] | TUBE YP0301- to | TUBE YP0301- to |
| 90. | 2418P12093D1 | [1] | TUBE | KOBYP0301- to |
| 91. | 2418P12093D2 | [1] | TUBE YP0301- to | TUBE YP0301- to |
| 92. | 2444R870D2 | [1] | FLEXIBLE HOSE | KOBYP0301- to |
