神钢零件查询(K905LC) - EXCAVATOR ASN YP1282 (1/85-12/03) (01-001) - FRAME ASSY, UPP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
843 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6541F7 | [1] | FRAME ASSY,UPP | |
| 2. | 2414T2341 | [1] | COVER | KOB Superseded by part number: YN52F01158P1 |
| 3. | 2414Z234 | [1] | COVER | KOB |
| 4. | 2418T12125 | [1] | PLATE | KOB Superseded by part number: YN52F01159P1 |
| 5. | 2416Z434 | [1] | PACKING | KOBRubber |
| 7. | 2420R561D1 | [1] | DIPSTICK | KOB |
| 8. | 2420T4039C207 | [1] | PIPE | |
| 9. | ZS13C10025 | [8] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 10. | ZS23C20055 | [12] | SCREW,Hex Socket Head, M20 x 55mm | KOBM20x2.5x55mm |
| 11. | ZS13C16080 | [25] | CAPSCREW | KOBSCREW M16x2.0x80mm |
| 13. | 2418T5373C2 | [8] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 14. | 2456Z253 | [1] | MIRROR | KOB |
| 18. | 2420T4561D1 | [3] | BOLT | KOBReamer -- M16x2.0x80mm |
| 20. | 2427N1676D1 | [1] | PROTECTOR | KOB |
| 21. | 2427N1676D2 | [1] | PROTECTOR | KOB |
| 22. | ZS18C12030 | [10] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 23. | ZW26X12000 | [12] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 24. | 2418T10357 | [12] | WASHER | KOBID 13 x OD 30 x Th 3.2mm Superseded by part number: 2418T12345 |
| 30. | 2416P13732 | [1] | STAY | KOB Superseded by part number: 2416P13732D2 |
| 31. | 2432T4113 | [1] | CLAMP | KOB Superseded by part number: 2432T4113D2 |
| 32. | ZS18C08040 | [2] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| 34. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 35. | 2422J2867 | [1] | FRAME,UPP | |
| 35-1. | 2414T2729 | [1] | COVER | KOB |
| 35-2. | ZS83C20020 | [1] | SCREW | KOBSet -- M20x2.50x20mm |
| 35-3. | 2405T1072 | [2] | BUSHING | KOB |
| 36. | 2427T1819F2 | [2] | PROTECTOR | KOB |
| 36-2. | 2427T1836 | [1] | FOAM INSULATION | KOB |
| 36-3. | 2427J2518 | [1] | PROTECTOR | PROTECTOR |
| 37. | NSS | [1] | NOT SOLD SEPARAT | CONMOTOR ASSY, SWING, SEE FIG:01-003 |
| 38. | ZS23C12030 | [2] | SCREW,Hex Socket Head, M12 x 30mm | KOBM12x1.75x30mm |
