| . . | 24100J4877F2 | [1] | CONTROL ASSY | CONTROL ASSY |
| 1. | 24100U321F1 | [1] | VALVE ASSY, SOLENOID | VALVE ASSY, SOLENOID |
| 2. | 2436U817F1 | [1] | VALVE | KOB |
| 3. | 2418T10340 | [1] | TUBE | |
| 4. | 2418T10341 | [1] | TUBE | |
| 5. | 2418T10342 | [1] | TUBE | |
| 6. | 2418P9707 | [1] | TUBE | |
| 7. | 2418T10351 | [2] | TUBE | KOB |
| 8. | 2418T10343 | [1] | TUBE | |
| 9. | 2418T10344 | [1] | TUBE | |
| 11. | ZF23F28016 | [4] | HYD CONNECTOR | KOB |
| 12. | ZF23H15006 | [1] | HYD CONNECTOR | KOB |
| 15. | ZF23F22008 | [1] | TOOL | KOB |
| 14. | ZF23B22000 | [1] | HYD CONNECTOR | HIT |
| 15. | 2444Z2121 | [1] | C0NNECTOR | |
| 16. | ZX28N12110 | [2] | HOSE | KOB |
| 17. | ZX28N08190 | [1] | HOSE | KOB |
| 18. | 2420R483D2 | [2] | HOSE | |
| 19. | ZD12P03400 | [2] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 20. | ZD12P02900 | [4] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 21. | ZD12P01800 | [4] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 22. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 23. | ZC36X15009 | [1] | CLAMP | KOB |
| 24. | 2416T9891 | [1] | BRACKET | |
| 25. | ZS13C12110 | [3] | SCREW | KOBM12x1.75x110mm Superseded by part number: ZS18C12110 |
| 26. | ZS13C08045 | [1] | SCREW | KOBM08x1.25x45mm Superseded by part number: ZS18C08045 |
| 27. | ZS13C10035 | [2] | SCREW | KOBM10x1.50x35mm Superseded by part number: ZS18C10035 |
| 28. | 2420P1502D1 | [4] | SCREW,M6 x 90mm | KOBM06x1.0x90mm |
| 29. | ZN12C12010 | [3] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12010 |
| 30. | ZN12C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 31. | ZN12C06005 | [6] | NUT | KOBM06x1.0mm Superseded by part number: ZN18C06005 |
| 32. | ZW22X12000 | [3] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 33. | ZW22X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 34. | ZW22X06000 | [4] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 35. | ZW16X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 37. | ZH32Z04000 | [1] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| 39. | ZH51K08000 | [2] | TEE | KOB |
| 40. | 2444Z2086D1 | [1] | TEE | KOB |
| 41. | ZH22Z06000 | [1] | CONNECTION | KOB |
| 42. | ZH22Z04000 | [1] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 43. | ZH21K08004 | [1] | HYD CONNECTOR | KOB |
| 45. | 2420R350D5 | [1] | HOSE, Serial Range: LP060l-858 | HOSE, Serial Range: LP060l-858 |
| . . | 2420R537D060 | [1] | HOSE ASSY.,9.60mm ID x 600mm L | KOB, Start Serial: LP0859 |
| 48. | 2420R349D170 | [2] | FLEXIBLE HOSE | KOB Superseded by part number: HX21E04170DX |
| 49. | ZX15K08008 | [1] | TUBE, NYLON | TUBE, NYLON |
| 50. | ZX15K08013 | [1] | TUBE, NYLON | TUBE, NYLON |
| 51. | ZX15K08035 | [1] | TUBE | KOB |
| 52. | ZX15K08040 | [1] | PLASTIC-RUBBER TUBE | KOB |
| 53. | ZX15K08070 | [2] | FLEXIBLE HOSE | KOB |
| 55. | 24100U322F1 | [1] | VALVE | KOB |
| 56. | ZS23C06025 | [2] | SCREW,Hex Socket Head, M6 x 25mm | KOBM06x1.0x25mm |
| 57. | 2422N655 | [1] | FRAME | FRAME |
| 57-1. | 2416T10830D2 | [1] | BRACKET | |
| 57-2. | 2422T419 | [1] | PLATE | |
| 57-3. | 2416T10831 | [1] | BRACKET | |
| 57-4. | 2416P7236D1 | [1] | BRACKET | KOB |
| 57-5. | 2416T9892 | [1] | PLATE | |
| 58. | ZE82T04000 | [1] | PLUG | KOB1/4" PT |
| 60. | ZF23F15008 | [2] | CONNECTOR | |
| 61. | ZF23H15008 | [1] | HYD CONNECTOR | KOB |
| 62. | ZN12C08007 | [1] | NUT | KOBM08x1.25mm Superseded by part number: 77278252, ZN18C08007 |
| 63. | NSS | [1] | NOT SOLD SEPARAT | CONLOCK WASHER |
| 64. | ZH32Z04006 | [1] | ELBOW | KOB |
| 70. | 2416Z301D12 | [1] | SHEET, RUBBER | SHEET, RUBBER |
| 71. | 2479Z886 | [1] | SWITCH | KOB Superseded by part number: YW50S00001P1 |
| 72. | ZS31C06016 | [3] | SCREW,Phillips Drive, Pan HD, M6 x 16mm | KOBM06x1.0x16mm |
| 73. | ZN16C06005 | [3] | NUT | KOBM06x1.0mm Superseded by part number: ZN18C06005 |
| 74. | ZW26X06000 | [3] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 79. | 2432Z290 | [5] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 80. | 2444Z2240 | [1] | CONNECTOR | |
| 81. | ZX15K08050 | [1] | PLASTIC-RUBBER TUBE | KOB |
| 82. | 2479U229 | [3] | RELAY | KOBASSY |
| 83. | 2479R768 | [1] | SENSOR | KOBHARNESS |
