神钢零件查询(K905LC) - MARK II EXCAVATOR BTW YP1001 - YP1281 (1/87-12/03) (11-022) - VALVE ASSY, CONTROL (P/N 2436U1236F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
621 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1236F1 | [1] | VALVE, CONTROL VALVE ASSY (EXTRA & DOZZER) | VALVE, CONTROL VALVE ASSY (EXTRA & DOZZER) |
| 1. | 2436Z416F1 | [1] | SECTION ASSY, INLET | SECTION ASSY, INLET |
| 2. | B36K0019E102 | [1] | SECTION ASSY, OUTLET | |
| 3. | 2436R593F1 | [1] | PLUNGER | KOBSEE FIG 11-001 |
| 4. | 2436R807F1 | [1] | SPOOL | KOBSEE FIG 11-014 |
| 5. | 2436R1094F1 | [1] | VALVE | KOBSEE FIG 11-016 |
| 6. | 2436R721F3 | [4] | HYDRAULIC VALVE | KOBSEE FIG 11-006 |
| 7. | 2420Z1266F1 | [1] | PLUG | KOB |
| 7-1. | 2420Z1266S1 | [1] | PLUG | |
| 7-2. | 2436U618S28 | [1] | O-RING | KOB Superseded by part number: ZD12P02400 |
| 7-3. | 2483U283S9 | [1] | O-RING | KOB Superseded by part number: ZD12P01100 |
| 7-4. | 2420Z1266S4 | [1] | PLUG | |
| 8. | B36K0019E112 | [4] | NUT | KOB |
| 9. | 2436U790S9 | [2] | TIE-ROD | KOB |
| 10. | 2436U281S8 | [2] | NUT | NUT |
| 11. | 2436U790S11 | [1] | TIE-ROD | KOB |
