| 1. |
84591014
|
[1] |
WIRE HARNESS
|
ZED
|
| 2. |
84591015
|
[1] |
WIRE HARNESS
|
ZED
|
| 3. |
84591016
|
[2] |
WIRE HARNESS
|
ZED
|
| 3. |
48017451
|
[2] |
WIRE HARNESS
|
ZED
|
| 4. |
47361131
|
[2] |
WIRE HARNESS
|
ZED
|
| 5. |
445394
|
[4] |
RIVET,Pop, 3/16" x 1/2" OAL
|
ZED
Superseded by part number: 151-573
|
| 6. |
47383952
|
[2] |
MOUNTING PLATE
|
ZED
|
| 7. |
84058158
|
[6] |
SIDE LAMP ASSY
|
ZED
|
| 8. |
86566990
|
[1] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
|
| 9. |
411809
|
[4] |
GROMMET
|
ZED
|
| 10. |
84058228
|
[6] |
BULB,12V, 5W
|
ZED
|
| 11. |
82013031
|
[2] |
CABLE TIE,193mm L
|
BAS
, Serial Range: -C084 Superseded by part number: 87718512
|
| 12. |
237910
|
[8] |
WIRE CLAMP,7.9mm, Coat, 7.1mm Bolt Hole, P Type
|
NH
, Serial Range: -C071
|
| 12. |
9507807
|
[1] |
CLAMP,8.3mm ID, 6.7mm Bolt Hole, P Type
|
ZED
, Start Serial: D072
|
| 14. |
84591018
|
[2] |
MOUNTING PLATE
|
ZED
|
| 14. |
48029625
|
[2] |
MOUNTING PLATE
|
ZED
|
| 15. |
322355
|
[12] |
BELLEVILLE WASHER,M4 Bolt Size x 10mm OD x 0.9mm Thk
|
NH
|
| 16. |
86511042
|
[12] |
SCREW,Pan Head, M4 x 0.7 x 16mm, Cl 4.8
|
ZED
Superseded by part number: 13272214
|
| 17. |
100012
|
[12] |
NUT,M4 x 0.7, Cl 8
|
NH
, Serial Range: -C071 Superseded by part number: 57121
|
| 17. |
385681
|
[12] |
NUT,M4 x 0.7, Cl 8
|
MKT
, Start Serial: D072
|
| 18. |
81844483
|
[2] |
PLUG,.73" x 1"
|
A
Superseded by part number: 81819333
|
| 19. |
86511830
|
[4] |
SCREW,Phillips Drive, Pan HD, M6 x 20mm, Cl 4.8
|
ZED
|
| 20. |
322357
|
[4] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 21. |
9706755
|
[4] |
NUT,M6, Cl 8
|
NH
, Serial Range: -C071 Superseded by part number: 86500688
|
| 21. |
353308
|
[4] |
NUT,M6 x 1.0, Cl 8
|
NH
, Start Serial: D072
|
| 22. |
8467255
|
[2] |
CLIP
|
BER
, Start Serial: D072 Superseded by part number: 73171113
|
| 23. |
82033028
|
[2] |
CABLE TIE,170mm L
|
BAS
, Start Serial: D085
|
| 24. |
9512290
|
[2] |
RIVET,Pop, 4.8mm OD x 17.8mm L
|
ZED
, Start Serial: D085
|
| 25. |
87564736
|
[2] |
CLAMP,14.3mm, Insul, M6 Bolt
|
WIC
, Start Serial: D085
|
| 26. |
140182
|
[2] |
WASHER,5.5mm ID x 18mm OD x 2mm Thk
|
ZED
, Start Serial: D085
|
