神钢零件查询(K907C) - EXCAVATOR BTW LN4201 - LN7000 (1/84-12/03) (15-016) - LABEL,NAME-PLATE (FOR LONG CRAWLER) P/N 24100J490F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
922 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J4904F2 | [1] | LABEL, NAME-PLATE | |
| 1. | 2432J669 | [2] | LABEL | KOB |
| 2. | 2452J1012 | [1] | NAME-PLATE | |
| 3. | NSS | [2] | NOT SOLD SEPARAT | CONSEAT |
| 4. | 2427Z329D3 | [1] | SHEET | KOBAnti-Slip (250x150mm) |
| 6. | 2432J1014 | [1] | LABEL | KOBLABEL Superseded by part number: 2432J1246 |
| 7. | 2432J1011 | [1] | NAME-PLATE | |
| 8. | 2432N578 | [1] | PLATE | KOB(ISO) |
| 9. | 2432T1231 | [1] | DATA PLAQUE | KOBDecal, Warning - |
| 10. | 2432T142D2 | [1] | PLATE, CAUTION | |
| 11. | 2432T12D2 | [1] | PLATE, CAUTION | |
| 12. | 2432T892 | [1] | LABEL | KOBPLATE, CAUTION |
| 13. | 2432T1759 | [1] | PLATE | KOB |
| 14. | 2432T1215 | [1] | DATA PLAQUE | KOBDecal, Caution - To prevent accidents and bodily injury … |
| 15. | 2432T1753 | [1] | LABEL | KOBDecal, Kobelco Operation Superseded by part number: YN20T01407P1 |
| 1 6. | 2432T1754 | [1] | LABEL | LABEL |
| 17. | 2437T1142 | [2] | LABEL | |
| 18. | 2418T10311 | [2] | PLATE | KOBØ30mm round Superseded by part number: 2418T27058 |
| 19. | 2432T1176 | [2] | LABEL | LABEL |
| 21. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE, NUMBER |
| 22. | 4020Z64 | [2] | RIVET | KOBOD 5.0 x 6.0mm Long Superseded by part number: 2420P623D7 |
| 23. | 2432T884 | [1] | LABEL | KOB |
