| 1. |
47554088
|
[1] |
WIRE HARNESS
|
ZED
Incl 2 - 7, Serial Range: -C150
|
| 1. |
47972521
|
[1] |
WIRE HARNESS
|
ZED
Incl 2 - 7, Start Serial: D151
|
| 1. |
47966442
|
[1] |
WIRE HARNESS
|
ZED
Incl 2 - 7
|
| 2. |
47695386
|
[1] |
PLATE
|
ZED
|
| 3. |
84191453
|
[3] |
SOCKET,12/24V, 20A
|
DUB
|
| 4. |
84279530
|
[1] |
FUSE,50A, Maxival, Red
|
ZED
Superseded by part number: 5173263
|
| 4. |
82012388
|
[1] |
FUSE,30A, Maxival, Green
|
BAS
Superseded by part number: 5173264
|
| 4. |
84157159
|
[1] |
FUSE,40A, Maxi, Orange
|
COE
|
| 5. |
84539290
|
[1] |
RELAY,12V, 50A
|
BRR
|
| 6. |
84127702
|
[1] |
FUSE,10A, Mini, Red
|
JES
Superseded by part number: 87522597
|
| 6. |
84127703
|
[1] |
FUSE,15A, Mini, Blue
|
JES
Superseded by part number: 87524877
|
| 6. |
84127704
|
[1] |
FUSE,20A, Mini, Yellow
|
JES
Superseded by part number: 10401190
|
| 6. |
84152583
|
[1] |
FUSE,7.5A, Mini, Brown
|
JES
Superseded by part number: 87522595
|
| 6. |
84153830
|
[1] |
FUSE,5A, Mini, Beige
|
JES
|
| 6. |
84320044
|
[1] |
FUSE,5 Amp
|
ZED
Tan Superseded by part number: 87693742
|
| 7. |
87655334
|
[1] |
RELAY,12V, 35A, Micro
|
WIC
|
| 8. |
47695689
|
[1] |
PLATE
|
ZED
|
| 9. |
47695382
|
[1] |
PLATE
|
ZED
|
| 10. |
47448624
|
[1] |
COVER ASSY
|
ZED
|
| 11. |
47604670
|
[4] |
DAMPER
|
ZED
|
| 12. |
47385274
|
[1] |
MODULE
|
NH
|
| 13. |
291186
|
[1] |
PROTECTION STRIP,9.9mm W
|
NH
L = 0.25m Superseded by part number: 47560081, 47560080
|
| 14. |
401310
|
[1] |
PROFILE
|
ZED
L = 0.29m
|
| 15. |
445394
|
[2] |
RIVET,Pop, 3/16" x 1/2" OAL
|
ZED
Superseded by part number: 151-573
|
| 16. |
322358
|
[8] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 17. |
43127
|
[4] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 18. |
322357
|
[11] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 19. |
120100
|
[1] |
BOLT,M6 x 20mm, Cl 8.8
|
NH
, Serial Range: -C137
|
| 19. |
120104
|
[1] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
, Start Serial: D138
|
| 21. |
86507486
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 22. |
9706690
|
[8] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 23. |
87556072
|
[4] |
NUT,Flng, 11.8mm OD x 19.8mm L
|
ZED
|
| 24. |
86625263
|
[2] |
WASHER,9mm ID x 20mm OD x 1.6mm Thk
|
ZED
|
| 25. |
9706755
|
[4] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 27. |
86639313
|
[2] |
WASHER,9mm ID x 24mm OD x 2mm Thk
|
RAC
, Serial Range: -F145150
|
| 30. |
84404932
|
[1] |
COVER
|
BUR
|
