凯斯零件查询(LB424S XL) - BALER (11/16-) (60.220.072) - PICK-UP, REEL - D137 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
742 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84607784
|
[1] |
CAM
|
ZED
|
| 2. |
47802528
|
[1] |
SHAFT
|
ZED
, Serial Range: -C143
|
| 2. |
47902237
|
[1] |
SHAFT
|
ZED
, Start Serial: D144
|
| 2. |
47535600
|
[1] |
SHAFT
|
ZED
, Serial Range: -C143
|
| 2. |
47902239
|
[1] |
SHAFT
|
ZED
, Start Serial: D144
|
| 3. |
47817044
|
[4] |
SHAFT
|
ZED
|
| 3. |
47525194
|
[4] |
SHAFT
|
ZED
|
| 4. |
84058012
|
[4] |
BUSHING,15.88mm ID x 30mm OD x 16mm L
|
ZED
|
| 5. |
47523018
|
[12] |
BALL BEARING
|
ZED
|
| 6. |
47521709
|
[24] |
FLANGE
|
ZED
|
| 7. |
84056924
|
[4] |
CAM FOLLOWER,Tine Shaft
|
ZED
|
| 8. |
446691
|
[4] |
WASHER,16mm ID x 32mm OD x 5mm Thk
|
ZED
|
| 9. |
86511416
|
[4] |
JAM NUT,Jam, 5/8"-18, G2
|
ZED
|
| 10. |
86633356
|
[1] |
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
|
ZED
|
| 11. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 12. |
84388371
|
[56] |
SPACER
|
PLO
|
| 13. |
84582461
|
[56] |
TINE
|
ZED
5.5MM
|
| 14. |
300423
|
[1] |
COTTER PIN,M6.3 x 50
|
WIN
|
| 15. |
9706704
|
[3] |
BOLT,Hex, M10 x 1.5 x 41.58mm, Cl 8.8
|
NH
|
| 16. |
140045
|
[1] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 17. |
84524588
|
[56] |
GUARD
|
PLO
|
| 18. |
80681
|
[1] |
LOCK NUT,5/16"
|
NH
Superseded by part number: 83990583
|
| 19. |
120061
|
[1] |
BOLT,Hex, M8 x 60mm L, Cl 8.8
|
NH
|
