凯斯零件查询(LB424S XL) - BALER (11/16-) (60.220.091) - FEED ROLLER - D085 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
687 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47501832
|
[1] |
FEED ROLLER
|
ZED
, Serial Range: -C087
|
| 1. |
47581248
|
[1] |
FEED ROLLER
|
ZED
, Serial Range: -F088144
|
| 1. |
47906539
|
[1] |
FEED ROLLER
|
ZED
, Start Serial: D145
|
| 1. |
84572481
|
[1] |
FEED ROLLER
|
ZED
, Serial Range: -C087 Superseded by part number: 47943470
|
| 1. |
47584004
|
[1] |
ROLLER
|
ZED
, Serial Range: -F088144
|
| 1. |
47906534
|
[1] |
FEED ROLLER
|
ZED
, Start Serial: D145
|
| 2. |
84568884
|
[1] |
SPROCKET
|
ZED
|
| 3. |
36403
|
[4] |
BEARING HOUSING
|
GI
Superseded by part number: 578189
|
| 4. |
9837842
|
[2] |
BEARING,35mm ID x 72mm OD x 19mm W
|
ZED
|
| 5. |
86633356
|
[3] |
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
|
ZED
|
| 6. |
140045
|
[6] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 7. |
100016
|
[6] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 8. |
84429871
|
[2] |
WASHER
|
PLO
|
| 9. |
442293
|
[2] |
WASHER,36mm ID x 50mm OD x 1.5mm Thk
|
ZED
|
| 10. |
9801096
|
[1] |
WASHER,13.5mm ID x 50.8mm OD x 4.76mm Thk
|
NH
|
| 11. |
300388
|
[1] |
BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8
|
NH
|
