神钢零件查询(K907LC) - MARK II EXCAVATOR BTW YQ0101 - YQ0564 (1/87-12/03) (01-001) - FRAME ASSY UPP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
180 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6509F3 | [1] | FRAME ASSY, UPP | |
| 2. | 2414T2341 | [1] | COVER | KOB Superseded by part number: YN52F01158P1 |
| 3. | 2414Z234 | [1] | COVER | KOB |
| 4. | 2418T12125 | [1] | PLATE | KOB Superseded by part number: YN52F01159P1 |
| 5. | 2416Z434 | [1] | PACKING | KOBRubber |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CONMOTOR ASSY, SWING |
| 7. | 2420R561D1 | [1] | DIPSTICK | KOB |
| 8. | 2420P1519D1 | [1] | PIPE | KOB |
| 9. | 24100P1564F1 | [1] | BOX ASSY, TOOL | BOX ASSY, TOOL |
| 9-1. | 2427P2492 | [1] | CAM BOX TOOL | CAM BOX TOOL |
| 9-2. | 2414P4756 | [1] | COVER | COVER |
| 9-3. | 2432Z451 | [1] | CATCH | KOB |
| 9-4. | ZS16C08016 | [4] | SCREW | KOBM08x1.25x16mm Superseded by part number: ZS18C08016 |
| 9-5. | ZS31C03008 | [2] | SCREW,Phillips Drive, Pan HD, M3 x 8mm | KOBM03x0.5x08mm |
| 9-6. | ZN16C08007 | [4] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 9-7. | ZN11C03003 | [2] | NUT | KOBM03x0.5mm |
| 9-8. | ZW22X08000 | [4] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 9-9. | ZW26X03000 | [2] | LOCK WASHER | HIT |
| 10. | ZS13C10025 | [8] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 11. | ZS23C20055 | [12] | SCREW,Hex Socket Head, M20 x 55mm | KOBM20x2.5x55mm |
| 12. | ZS18C12020 | [2] | SCREW,Hex, M12 x 20mm | KOBM12x1.75x20mm |
| 13. | ZS13C20110 | [29] | CAPSCREW | KOBSCREW M20x2.50x110mm |
| 14. | 2420T4564D1 | [3] | BOLT | KOBReamer -- M20x2.50x110mm |
| 15. | 2418T5373C2 | [8] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 16. | ZW26X12000 | [20] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm, Serial Range: YQ0101-YQ0156 |
| 17. | 2418T10357 | [20] | WASHER | KOBID 13 x OD 30 x Th 3.2mm, Serial Range: YQ0101-YQ0156 Superseded by part number: 2418T12345 |
| 18. | ZW13H20000 | [32] | WASHER | KOBID 20 x OD 40 x Th 4.5mm |
| 19. | 2456Z253 | [1] | MIRROR | KOBBACK |
| 20. | 2406P2568 | [1] | STAY | KOB |
| 21. | 2427N1672D1 | [1] | PROTECTOR | KOB |
| 22. | ZS18C12030 | [18] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm, Serial Range: YQ0101-YQ0156 |
| 24. | 24100P1767F1 | [2] | PROTECTOR | KOB |
| 24-1. | 2427J1322 | [1] | PROTECTOR | KOBPROTECTOR |
| 24-2. | 2427T1836 | [1] | FOAM INSULATION | KOB |
| 25. | 2427N1672D2 | [1] | PROTECTOR | KOB |
| 27. | 2422J1972 | [1] | FRAME, UPP | |
| 27-1. | 2405T1256 | [2] | BUSHING | KOB |
| 27-2. | 2414T2784 | [1] | COVER | KOBID 95 X OD 146.4 x Th 06mm |
| 27-3. | ZS83C20020 | [1] | SCREW | KOBSet -- M20x2.50x20mm |
