| 1. |
47445677
|
[2] |
BEARING CUP
|
PLO
|
| 2. |
47445678
|
[1] |
BALL BEARING
|
PLO
|
| 3. |
47781187
|
[1] |
BEARING LOCK NUT
|
ZED
|
| 4. |
47910722
|
[1] |
PLATE
|
ZED
|
| 5. |
84062423
|
[12] |
SHIM
|
ZED
|
| 6. |
47930714
|
[1] |
RING
|
ZED
|
| 7. |
47946590
|
[3] |
RING
|
ZED
|
| 8. |
47911990
|
[9] |
RING
|
ZED
|
| 9. |
47884174
|
[6] |
MOUNTING PLATE
|
ZED
|
| 10. |
47981572
|
[1] |
SHAFT
|
ZED
|
| 10. |
47976997
|
[1] |
SHAFT
|
ZED
|
| 11. |
47970214
|
[1] |
BUSHING
|
ZED
|
| 12. |
86625140
|
[1] |
SNAP RING,M20, Ext
|
IMO
|
| 13. |
84012754
|
[1] |
O-RING,5mm Thk x 25mm ID, 70 Duro
|
ZED
|
| 14. |
47963371
|
[1] |
RING
|
ZED
|
| 15. |
47963505
|
[1] |
RUBBER SEAL
|
ZED
|
| 16. |
47935081
|
[1] |
BALL BEARING
|
ZED
|
| 17. |
47910055
|
[3] |
TUBE
|
ZED
, Serial Range: -C159
|
| 18. |
47680163
|
[1] |
SPROCKET
|
ZED
|
| 19. |
47934522
|
[1] |
SUPPORT
|
ZED
|
| 20. |
47794657
|
[1] |
CHAIN
|
PLO
Incl 21
|
| 21. |
47783767
|
[1] |
CONNECTING LINK
|
ZED
|
| 22. |
47910667
|
[3] |
TUBE
|
ZED
|
| 23. |
47911312
|
[1] |
PLATE
|
ZED
|
| 24. |
84429871
|
[12] |
WASHER
|
PLO
|
| 25. |
9801096
|
[1] |
WASHER,13.5mm ID x 50.8mm OD x 4.76mm Thk
|
NH
|
| 26. |
9706687
|
[1] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 27. |
120044
|
[4] |
CARRIAGE BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 28. |
140046
|
[8] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 29. |
9706685
|
[11] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 30. |
86633356
|
[1] |
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
|
ZED
|
| 31. |
140045
|
[1] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 32. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 33. |
120106
|
[3] |
BOLT,M8 x 1.25 x 45.45mm, Cl 8.8
|
NH
, Serial Range: -C159 Superseded by part number: 16044024
|
| 34. |
14422121
|
[3] |
HEX SOC SCREW,M12 x 35mm, Cl 8.8, Full Thd
|
MKT
|
| 35. |
14422021
|
[3] |
HEX SOC SCREW,M12 x 30mm, Cl 8.8
|
IMO
Superseded by part number: 56714
|
| 36. |
9706704
|
[3] |
BOLT,Hex, M10 x 1.5 x 41.58mm, Cl 8.8
|
NH
|
| 37. |
9628065
|
[4] |
SCREW,Hex, M12 x 1.75 x 45mm, Cl 8.8
|
NH
|
| 38. |
86595832
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, M16 x 40mm, Cl 8.8, Full Thd
|
NH
, Serial Range: -C159
|
| 38. |
87495304
|
[4] |
FLANGE BOLT,M6 x 55.4mm, Cl 10.9
|
BRR
, Start Serial: D160 Superseded by part number: 86978772
|
| 39. |
140048
|
[4] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
, Serial Range: -C159
|
| 39. |
86589278
|
[4] |
BELLEVILLE WASHER,17mm ID x 41.5mm OD x 4.5mm Thk
|
NH
, Start Serial: D160
|
| 40. |
100020
|
[4] |
NUT,M16 x 2.0, Cl 8
|
NH
|
