凯斯零件查询(LB424S XL) - BALER (11/16-) (60.280.025) - FEED CHAMBER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
723 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47959869
|
[1] |
CHANNEL
|
ZED
Incl 2 - 5
|
| 2. |
47946646
|
[1] |
PIN
|
ZED
|
| 3. |
84606844
|
[1] |
BELLEVILLE WASHER
|
ZED
|
| 4. |
100024
|
[1] |
NUT,M24 x 1.5, Cl 8
|
MKT
|
| 5. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Plate, Incl in 1
|
| 6. |
47810991
|
[1] |
PLATE
|
ZED
|
| 7. |
48052042
|
[1] |
MOUNTING PLATE
|
ZED
|
| 7. |
84498172
|
[1] |
MOUNTING PLATE
|
ZED
|
| 8. |
47857536
|
[2] |
GUIDE
|
ZED
|
| 9. |
47859397
|
[3] |
GUIDE
|
ZED
|
| 9. |
47646898
|
[6] |
GUIDE
|
ZED
|
| 10. |
47856817
|
[2] |
GUIDE
|
ZED
|
| 11. |
9839098
|
[1] |
ROD,25mm OD x 1249mm L
|
ZED
|
| 12. |
394631
|
[20] |
WASHER,17mm ID x 34mm OD x 4mm Thk
|
NH
|
| 13. |
43168
|
[7] |
BOLT,Hex, M16 x 40mm, Cl 8.8
|
NH
Superseded by part number: 86509867
|
| 14. |
100020
|
[2] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 15. |
338949
|
[22] |
CARRIAGE BOLT,M10 x 1.5 x 25mm, Cl 8.8
|
NH
|
| 16. |
140045
|
[36] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 17. |
100016
|
[36] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 18. |
300423
|
[2] |
COTTER PIN,M6.3 x 50
|
WIN
|
| 19. |
86633356
|
[4] |
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
|
ZED
|
| 20. |
43435
|
[4] |
FLANGE NUT,Hex, M10 x 1.5
|
WIN
|
| 21. |
334966
|
[4] |
CARRIAGE BOLT,Sht Nk, M12 x 1.75 x 45mm, Cl 8.8, Full Thd
|
PA
|
| 22. |
140046
|
[4] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 23. |
9706685
|
[8] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 24. |
120090
|
[2] |
BOLT,Hex, M16 x 50mm, Cl 8.8
|
NH
|
| 25. |
86000441
|
[8] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 26. |
47963523
|
[1] |
SPACER
|
ZED
|
| 27. |
321246
|
[1] |
BOLT,Hex, M16 x 2 x 120mm, Cl 8.8
|
NH
|
| 28. |
412237
|
[6] |
CARRIAGE BOLT,Short Sq Nk, M10 x 25mm, Cl 8.8
|
ZED
Superseded by part number: 80412237
|
