凯斯零件查询(LB424S XL) - BALER (11/16-) (60.280.070) - SHUTTLE FEEDER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
239 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84513861
|
[1] |
ARM
|
ZED
, Serial Range: -C055 Superseded by part number: 47444822
|
| 1. |
47444822
|
[1] |
ARM
|
ZED
, Start Serial: D056
|
| 2. |
370004
|
[2] |
SNAP RING,M35 x 1.5mm Thk, External
|
NH
Superseded by part number: 11068376
|
| 3. |
84294723
|
[1] |
TUBE
|
ZED
|
| 3. |
84281613
|
[1] |
TUBE
|
ZED
|
| 4. |
84513872
|
[1] |
ARM
|
ZED
|
| 5. |
47372836
|
[1] |
FORK
|
ZED
|
| 5. |
47372864
|
[1] |
FORK
|
ZED
|
| 5. |
47365174
|
[1] |
FORK
|
ZED
|
| 5. |
47741296
|
[1] |
FORK
|
ZED
, Start Serial: D103
|
| 5. |
84487605
|
[1] |
FORK
|
ZED
|
| 5. |
47720370
|
[1] |
FORK
|
ZED
, Start Serial: D103
|
| 5. |
47372405
|
[1] |
FORK
|
ZED
|
| 6. |
536632
|
[6] |
BOLT
|
MKT
Superseded by part number: 86508619
|
| 7. |
100016
|
[6] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 8. |
100037
|
[6] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 9. |
84100982
|
[1] |
CANVAS
|
ZED
|
| 10. |
84043413
|
[1] |
COVER PLATE
|
ZED
|
| 11. |
120101
|
[2] |
BOLT,Hex, M6 x 1 x 30mm, Cl 8.8
|
NH
Superseded by part number: 87317695
|
| 12. |
353308
|
[2] |
NUT,M6 x 1.0, Cl 8
|
NH
|
| 13. |
87391000
|
[1] |
RETAINER
|
ZED
|
| 14. |
378247
|
[1] |
WASHER,21mm ID x 39mm OD x 3mm Thk
|
ZED
|
| 15. |
370024
|
[1] |
CIRCLIP,M20, Ext
|
NH
|
| 16. |
84068861
|
[1] |
SPRING
|
ZED
|
| 17. |
84295831
|
[2] |
RING
|
ZED
|
| 18. |
84247661
|
[2] |
BEARING
|
ZED
|
| 19. |
84295835
|
[4] |
WASHER
|
ZED
|
| 20. |
84277164
|
[2] |
CIRCLIP
|
ZED
|
| 21. |
300502
|
[4] |
HEX SOC SCREW,FLAT, M12 x 1.75 x 40mm, Cl 8.8
|
ZED
|
| 22. |
100038
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 23. |
84480731
|
[2] |
SLEEVE
|
ZED
|
| 24. |
80140184
|
[1] |
WASHER,31mm ID x 50mm OD x 3mm Thk
|
ZED
|
| 25. |
325594
|
[2] |
WASHER,M17 x 40mm OD x 5mm Thk
|
ZED
|
| 26. |
355259
|
[2] |
BOLT,Hex, M16 x 65, 8.8
|
ZED
|
| 27. |
86000441
|
[2] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 28. |
84310233
|
[2] |
RUBBER STRIP
|
ZED
|
| 29. |
47434040
|
[1] |
PLATE
|
ZED
, Serial Range: -F056093
|
| 29. |
47610325
|
[1] |
PLATE
|
ZED
, Start Serial: D094
|
| 30. |
43127
|
[2] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
, Start Serial: D056
|
| 31. |
86624184
|
[4] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
FOR
, Start Serial: D056
|
| 32. |
43362
|
[2] |
NUT,M8 x 1.25, Cl 10
|
BHB
, Start Serial: D056
|
