| 1. |
84492821
|
[1] |
ARM
|
ZED
,, Serial Range: -C055 Superseded by part number: 47404048
|
| 1. |
47404048
|
[1] |
PIVOT
|
ZED
,, Serial Range: -F056130
|
| 1. |
47786969
|
[1] |
PIVOT
|
ZED
, Start Serial: D131
|
| 2. |
84011609
|
[2] |
INSULATOR BLOCK
|
ZED
|
| 3. |
394631
|
[8] |
WASHER,17mm ID x 34mm OD x 4mm Thk
|
NH
|
| 4. |
412398
|
[4] |
BOLT,Hex, M16 x 2 x 50mm, Cl 10.9, Full Thd
|
NH
|
| 5. |
84247660
|
[2] |
BEARING
|
ZED
|
| 6. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 7. |
84817410
|
[2] |
PIN,25.4mm OD x 60mm L
|
ZED
|
| 8. |
84492828
|
[1] |
ARM
|
ZED
,, Serial Range: -C055 Superseded by part number: 47407317
|
| 8. |
47407317
|
[1] |
PIVOT
|
ZED
,, Serial Range: -F056093
|
| 8. |
47636352
|
[1] |
PIVOT
|
ZED
,, Serial Range: -F094130
|
| 8. |
47786962
|
[1] |
PIVOT
|
ZED
, Start Serial: D131
|
| 9. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 10. |
43140
|
[2] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
,, Serial Range: -C055
|
| 10. |
120069
|
[2] |
BOLT,M10 x 1.5 x 56.58mm OAL, Cl 8.8
|
NH
,, Start Serial: D056
|
| 11. |
9820493
|
[4] |
WASHER,20.5mm ID x 35mm OD x 2mm Thk
|
ZED
|
| 12. |
9839123
|
[2] |
BEARING ASSY,20mm ID x 52mm OD x 25mm W
|
ZED
|
| 13. |
84294711
|
[4] |
BUSHING
|
ZED
|
| 14. |
84294911
|
[1] |
BRACKET
|
ZED
|
| 15. |
84294915
|
[2] |
BUSHING
|
ZED
|
| 16. |
84294913
|
[1] |
BRACKET
|
ZED
|
| 17. |
84293751
|
[2] |
PLATE
|
ZED
|
| 18. |
9801096
|
[2] |
WASHER,13.5mm ID x 50.8mm OD x 4.76mm Thk
|
NH
|
| 19. |
9706687
|
[2] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 20. |
392530
|
[4] |
NUT,M16, Cl 10
|
NH
|
| 21. |
322359
|
[2] |
BELLEVILLE WASHER,M20 Bolt Size x 40mm OD x 3.2mm Thk
|
NH
|
| 22. |
86639847
|
[2] |
WASHER,21.8mm ID x 44.5mm OD x 5mm Thk
|
RAC
|
| 23. |
320771
|
[2] |
NUT,Thin, M20 x 1.5, Cl 04
|
NH
|
| 24. |
84295845
|
[2] |
RING,76mm ID x 95mm OD x 5.5mm Thk
|
ZED
|
| 25. |
84294991
|
[1] |
SHIM
|
ZED
|
| 26. |
84294990
|
[1] |
SHIM
|
ZED
|
| 27. |
84295971
|
[1] |
TUBE
|
ZED
|
| 28. |
84295967
|
[1] |
TUBE
|
ZED
|
| 29. |
84306711
|
[2] |
SHIM,4mm Thk
|
ZED
|
| 30. |
84306714
|
[20] |
SHIM,0,5mm Thk
|
ZED
|
| 31. |
84467156
|
[1] |
CARRIAGE BOLT,Reg Sq Nk, M8 x 1.25 x 120mm
|
ZED
|
| 32. |
84467157
|
[1] |
CARRIAGE BOLT,Reg Sq Nk, M8 x 1.25 x 160mm
|
ZED
|
| 33. |
86624184
|
[2] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
FOR
, Serial Range: -C130
|
| 34. |
9706690
|
[4] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 35. |
84392497
|
[2] |
SHAFT
|
ZED
|
| 36. |
12646205
|
[2] |
WASHER,M8 x 35 x 3
|
BAS
, Serial Range: -C140
|
| 36. |
12646201
|
[2] |
WASHER,8.15mm ID x 35mm OD x 3mm Thk
|
TTF
, Start Serial: D141 Superseded by part number:
|
| 37. |
120062
|
[2] |
BOLT,Hex, M8 x 70mm, Cl 8.8
|
NH
Superseded by part number: 7120024
|
| 38. |
47440102
|
[2] |
SHIM
|
ZED
,, Start Serial: D056
|
