凯斯零件查询(LB424S XL) - BALER (11/16-) (60.290.030) - MAIN TRANSMISSION TO SHUTTLE FEEDER PTO Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
547 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84806913
|
[1] |
HUB
|
ZED
|
| 2. |
84806307
|
[1] |
DISC
|
ZED
|
| 3. |
84806287
|
[1] |
HUB
|
ZED
|
| 4. |
84074031
|
[1] |
SHAFT
|
ZED
Superseded by part number: 84068096
|
| 4. |
84074032
|
[1] |
SHAFT
|
ZED
Superseded by part number: 84068097
|
| 5. |
84053926
|
[1] |
HYD CONNECTOR
|
ZED
|
| 6. |
86508570
|
[1] |
BOLT,Hex, M6 x 80mm OAL, Cl 8.8
|
NH
|
| 7. |
353308
|
[1] |
NUT,M6 x 1.0, Cl 8
|
NH
|
| 8. |
321204
|
[2] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 9. |
140048
|
[8] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 10. |
43168
|
[8] |
BOLT,Hex, M16 x 40mm, Cl 8.8
|
NH
Superseded by part number: 86509867
|
