凯斯零件查询(LB424S XL) - BALER (11/16-) (68.120.050) - ELECTRIC BALE LENGHT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
302 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84315608
|
[1] |
LEVER
|
ZED
|
| 2. |
34439
|
[2] |
BALL BEARING,25 mm ID x 52 mm OD x 15 mm
|
NNA
Superseded by part number: 443898
|
| 3. |
84405423
|
[1] |
CAM
|
ZED
|
| 4. |
47368091
|
[1] |
ARM
|
ZED
, Serial Range: -C084 Superseded by part number: 47432458
|
| 4. |
47432458
|
[1] |
ARM
|
ZED
, Start Serial: D085
|
| 5. |
140017
|
[1] |
WASHER,M10 x 20mm OD x 2mm Thk
|
PA
Superseded by part number: 9820489
|
| 6. |
84004515
|
[1] |
CAM FOLLOWER
|
ZED
, Serial Range: -C150
|
| 6. |
86624176
|
[1] |
WASHER,11mm ID x 20mm OD x 2mm Thk
|
FOR
, Start Serial: D151 Superseded by part number: 14496621
|
| 7. |
140045
|
[3] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 8. |
84022934
|
[1] |
NUT,M10 x 1, Cl 8
|
ZED
|
| 9. |
338206
|
[4] |
WASHER,26mm ID x 35mm OD x 2mm Thk
|
ZED
|
| 10. |
84607112
|
[1] |
STOP
|
ZED
|
| 11. |
120041
|
[2] |
CARRIAGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 12. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 13. |
322357
|
[3] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 14. |
86508568
|
[3] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8
|
NH
|
| 15. |
86505868
|
[1] |
SERRATED NUT,Hex, M8 x 1.25, Cl 8
|
ZED
|
| 16. |
84412941
|
[1] |
ADJUSTER
|
ZED
, Serial Range: -C084
|
| 17. |
385188
|
[6] |
SHIM,26mm ID x 34mm OD x 0.5mm Thk
|
PA
|
| 18. |
47427520
|
[1] |
SUPPORT
|
ZED
|
| 19. |
322358
|
[1] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 20. |
43128
|
[1] |
BOLT,M8 x 1.25 x 30mm, Cl 8.8
|
NH
|
