| 1. |
84529290
|
[2] |
DISC
|
ZED
|
| 2. |
9838303
|
[1] |
GEAR
|
ZED
|
| 3. |
86000441
|
[1] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 4. |
34439
|
[2] |
BALL BEARING,25 mm ID x 52 mm OD x 15 mm
|
NNA
Superseded by part number: 443898
|
| 5. |
47368131
|
[1] |
LEVER
|
ZED
, Serial Range: -C084
|
| 5. |
47492595
|
[1] |
LEVER
|
ZED
, Start Serial: D085
|
| 6. |
338206
|
[4] |
WASHER,26mm ID x 35mm OD x 2mm Thk
|
ZED
|
| 7. |
370002
|
[1] |
CIRCLIP,M25, External
|
NH
|
| 8. |
84529279
|
[1] |
SECTOR
|
ZED
, Serial Range: -C144
|
| 8. |
47771883
|
[1] |
SECTOR
|
ZED
, Serial Range: -F145148
|
| 8. |
47956267
|
[1] |
SECTOR
|
ZED
, Start Serial: D149
|
| 9. |
84031241
|
[1] |
SUPPORT
|
ZED
|
| 10. |
647695
|
[1] |
PIN,7.94mm OD
|
NH
|
| 11. |
84529284
|
[1] |
PLATE
|
ZED
, Serial Range: -C144 Superseded by part number: 47771895, 47771883
|
| 11. |
47771895
|
[1] |
PLATE
|
ZED
, Start Serial: D145
|
| 12. |
84032061
|
[1] |
PLATE
|
ZED
|
| 13. |
86508568
|
[2] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8
|
NH
, Serial Range: -C144
|
| 13. |
120100
|
[2] |
BOLT,M6 x 20mm, Cl 8.8
|
NH
, Start Serial: D145
|
| 14. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 15. |
9706755
|
[2] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 16. |
84607524
|
[1] |
BUSHING,10.5mm ID x 16mm OD x 17.5mm L
|
ZED
|
| 17. |
378244
|
[2] |
WASHER,10.5mm ID x 24mm OD x 2mm Thk
|
NH
|
| 18. |
9706704
|
[1] |
BOLT,Hex, M10 x 1.5 x 41.58mm, Cl 8.8
|
NH
|
| 19. |
140045
|
[1] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 20. |
100016
|
[3] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 21. |
86512420
|
[1] |
CARRIAGE BOLT,Rnd Head, M8 x 1.25 x 20mm, Full Thd, Cl 8.8
|
NH
, Serial Range: -C144
|
| 22. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 23. |
9706690
|
[2] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 24. |
9812123
|
[1] |
BUSHING,8.5mm ID x 16mm OD x 7mm L
|
ZED
|
| 25. |
43127
|
[1] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 26. |
86624184
|
[1] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
FOR
|
| 27. |
9838297
|
[1] |
CLEVIS,M12
|
ZED
|
| 28. |
84393194
|
[1] |
ROD
|
ZED
|
| 29. |
323238
|
[1] |
THIN NUT,Hex, M12, 1.75mm Pitch, Cl 05
|
ZED
|
| 30. |
378245
|
[1] |
WASHER,13mm ID x 28.5mm OD x 2.7mm Thk
|
NH
|
| 31. |
200091
|
[1] |
BUSHING
|
ZED
|
| 32. |
9838295
|
[1] |
BOLT
|
ZED
|
| 33. |
9838278
|
[1] |
SPRING
|
ZED
|
| 34. |
86629541
|
[1] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 35. |
100038
|
[1] |
NUT,M12 x 1.75, Cl 8
|
NH
|
