| 1. |
84244235
|
[1] |
TWINE
|
ZED
Incl 2 - 9
|
| 1. |
84244248
|
[1] |
TWINE
|
ZED
Incl 2 - 9
|
| 2. |
84244236
|
[1] |
SHAFT
|
ZED
|
| 2. |
84244249
|
[1] |
SHAFT
|
ZED
|
| 3. |
87521132
|
[1] |
ROPE GUIDE ROLLER,31.5mm OD x 12mm L
|
ZED
Superseded by part number: 47508395
|
| 4. |
84014757
|
[1] |
BUSHING,12mm ID x 25mm OD x 14mm L
|
ZED
|
| 5. |
9838366
|
[1] |
ROLLER,32mm OD x 40mm L
|
ZED
|
| 6. |
84607927
|
[1] |
SCREW,#10 - 32 x 0.55",
|
ZED
, Serial Range: -C047
|
| 6. |
84597445
|
[1] |
SCREW,FLAT, M5 x 14mm
|
ZED
, Start Serial: D048
|
| 7. |
9838237
|
[1] |
HEX SOC SCREW,CSS, #10 - 32 x 1/2"
|
ZED
, Serial Range: -C047
|
| 7. |
84597481
|
[1] |
SCREW,CSS, M5 x 12.9mm
|
ZED
, Start Serial: D048
|
| 8. |
140046
|
[1] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 9. |
399555
|
[1] |
THIN NUT,Thin, M12 x 1.5, Cl 04
|
ZED
|
| 10. |
87666776
|
[1] |
HOUSING
|
ZED
|
| 11. |
84817518
|
[1] |
BALL BEARING,25mm ID x 47mm OD x 12mm W
|
ZED
|
| 12. |
87665393
|
[1] |
PLATE
|
ZED
|
| 13. |
9837806
|
[1] |
FLANGED BEARING,25mm ID
|
ZED
|
| 14. |
120038
|
[2] |
CARRIAGE BOLT,Rnd Head, M8 x 1.25 x 30mm, Cl 8.8, Full Thd
|
NH
Superseded by part number: 811-8030
|
| 15. |
322358
|
[6] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 16. |
9706690
|
[6] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 17. |
120068
|
[2] |
BOLT,Hex, M10 x 40mm, Cl 8.8
|
NH
|
| 18. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 19. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 20. |
84819382
|
[2] |
SUPPORT
|
ZED
|
| 21. |
86507486
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 22. |
87331610
|
[6] |
GUIDE
|
ZED
, Serial Range: -C047
|
| 22. |
84275921
|
[6] |
GUIDE
|
ZED
, Start Serial: D048
|
| 23. |
370004
|
[6] |
SNAP RING,M35 x 1.5mm Thk, External
|
NH
Superseded by part number: 11068376
|
| 24. |
9838862
|
[2] |
SPRING
|
ZED
|
