| 1. |
412250
|
[1] |
NUT,M8 x 1.25, Cl 8
|
WIN
Superseded by part number: 86528579
|
| 2. |
86624184
|
[1] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
FOR
|
| 3. |
9838781
|
[1] |
SPRING CLIP
|
ZED
|
| 4. |
84807244
|
[2] |
HYD CONNECTOR
|
ZED
|
| 5. |
84143494
|
[1] |
CAM
|
ZED
|
| 6. |
9838815
|
[1] |
GEAR
|
ZED
|
| 7. |
87371864
|
[2] |
COTTER PIN,5.13mm OD x 30mm L
|
ZED
|
| 8. |
84807243
|
[3] |
HYD CONNECTOR
|
ZED
|
| 9. |
84801677
|
[2] |
PIN,9.35mm OD x 28mm L
|
ZED
|
| 10. |
87516541
|
[1] |
STUD
|
ZED
|
| 11. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 12. |
300627
|
[1] |
SNAP RING,M19, External
|
ZED
|
| 13. |
87519070
|
[3] |
SHIM,20mm ID x 26mm OD x 0.2mm Thk
|
ZED
|
| 14. |
84018542
|
[2] |
SHIM,20mm ID x 26mm OD x 0.5mm Thk
|
ZED
|
| 15. |
84807245
|
[1] |
COUPLING
|
ZED
|
| 16. |
9838785
|
[2] |
SPRING CLIP
|
ZED
,, Serial Range: -C023 Superseded by part number: 84401492
|
| 16. |
84401492
|
[2] |
LEAF SPRING
|
ZED
,, Start Serial: D024
|
| 17. |
43140
|
[1] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 18. |
9838812
|
[1] |
COILED PIN
|
ZED
|
| 19. |
9838787
|
[1] |
GEAR
|
ZED
|
| 20. |
87519080
|
[7] |
SHIM,15mm ID x 21mm OD x 0.2mm Thk
|
ZED
|
| 21. |
84004344
|
[1] |
WORM SCREW
|
ZED
Incl 24 - 26, 52
|
| 22. |
84018614
|
[2] |
ADJUSTING PLATE
|
ZED
|
| 23. |
84007145
|
[4] |
SHIM,15mm ID x 21mm OD x 1mm Thk
|
ZED
|
| 24. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Vis Sans Fin Incl in 21
|
| 25. |
140028
|
[1] |
WASHER,10.2mm ID x 18.1mm OD x 2.2mm Thk
|
NH
|
| 26. |
84022934
|
[1] |
NUT,M10 x 1, Cl 8
|
ZED
|
| 27. |
87645098
|
[1] |
BILL HOOK
|
ZED
Incl 48, 50, Serial Range: -C098
|
| 27. |
9838791
|
[1] |
BILL HOOK
|
ZED
, Start Serial: D099
|
| 28. |
9838790
|
[1] |
PIN,5mm OD x 16mm L
|
ZED
|
| 29. |
87645121
|
[1] |
BILL HOOK
|
ZED
Incl 27, 28, 47, 48 ,50, Serial Range: -C098
|
| 29. |
9838789
|
[1] |
BILL HOOK
|
ZED
, Start Serial: D099 Superseded by part number: 87645121, 84143494
|
| 30. |
87330787
|
[1] |
TWINE RETAINER
|
ZED
|
| 31. |
84790414
|
[1] |
DISC
|
ZED
|
| 32. |
9838799
|
[1] |
CLEANER
|
ZED
|
| 33. |
86050276
|
[1] |
BOLT,Hex, M5 x 16mm, Cl 8.8, Full Thd
|
NH
|
| 34. |
322356
|
[1] |
BELLEVILLE WASHER,M5 Bolt Size x 12mm OD x 1.85mm Thk
|
ZED
|
| 35. |
9838803
|
[1] |
KNIFE,48mm L x 27mm W x 2mm Thk
|
ZED
|
| 36. |
9838804
|
[1] |
SUPPORT
|
ZED
|
| 37. |
100038
|
[1] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 38. |
140046
|
[1] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 39. |
87728047
|
[1] |
ARM
|
ZED
Incl 23, 33 - 38, 40 TO 42, 51
|
| 40. |
84819569
|
[1] |
PIN,16mm OD x 82.5mm L
|
ZED
|
| 41. |
9838802
|
[1] |
ROLLER
|
ZED
|
| 42. |
301614
|
[1] |
SNAP RING,M14, Ext
|
ZED
Superseded by part number: 11066276
|
| 43. |
84819567
|
[1] |
SPACER,19.72mm ID x 22mm OD x 39.5mm L
|
ZED
|
| 44. |
84819566
|
[1] |
KNOTTER
|
ZED
Incl 9, 10, 43, 45, 46, 53, 56
|
| 46. |
43139
|
[2] |
BOLT,M10 x 1.5 x 25mm, Cl 8.8
|
NH
Superseded by part number: 11106231
|
| 47. |
9838794
|
[1] |
BILL HOOK
|
ZED
|
| 49. |
87620494
|
[1] |
GEAR
|
ZED
|
| 52. |
84345897
|
[1] |
SHAFT
|
ZED
|
| 53. |
87728048
|
[1] |
KNOTTER
|
ZED
Incl 1 - 52, 54 - 56, Serial Range: -C144
|
| 53. |
47728319
|
[1] |
KNOTTER
|
ZED
Incl 1 - 52, 54 - 56, Start Serial: D145
|
| 54. |
84560232
|
[1] |
RETAINER COLLAR
|
ZED
,, Start Serial: D024
|
| 55. |
84345905
|
[1] |
KNOTTER FRAME
|
ZED
Superseded by part number: 84819566
|
