凯斯零件查询(LB424S XL) - BALER (11/16-) (68.160.040) - KNOTTER BLOW OFF KIT, AIR RESERVOIR - D122 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
637 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47781238
|
[1] |
STUD
|
ZED
|
| 2. |
47781327
|
[1] |
TUBE
|
ZED
L = 1,65 M
|
| 3. |
47781310
|
[11] |
WASHER
|
ZED
|
| 4. |
47781920
|
[11] |
NUT
|
ZED
|
| 5. |
47781243
|
[1] |
TANK
|
ZED
|
| 6. |
47781245
|
[1] |
FITTING
|
ZED
|
| 7. |
47781287
|
[1] |
WIRE CONNECTOR
|
ZED
|
| 8. |
47781289
|
[1] |
COUPLING
|
ZED
|
| 9. |
47781290
|
[1] |
DUST CAP
|
ZED
|
| 10. |
47781294
|
[1] |
VALVE
|
ZED
|
| 11. |
47781303
|
[1] |
SOLENOID VALVE
|
ZED
|
| 12. |
47781305
|
[1] |
STUD
|
ZED
|
| 13. |
47781308
|
[1] |
STUD
|
ZED
|
| 14. |
47781312
|
[2] |
SEAL
|
ZED
|
| 15. |
47781313
|
[1] |
FITTING
|
ZED
Superseded by part number: 47441838
|
| 16. |
47781318
|
[2] |
SUPPORT
|
ZED
|
| 17. |
47781317
|
[1] |
TUBE
|
ZED
|
| 18. |
47781319
|
[1] |
WIRE
|
ZED
L = 7 M
|
| 19. |
47781325
|
[1] |
WIRE CONNECTOR
|
ZED
|
| 20. |
47781329
|
[1] |
SUPPORT
|
ZED
|
| 21. |
47781330
|
[2] |
SCREW
|
ZED
Superseded by part number: 47441846
|
| 22. |
47781334
|
[2] |
SPACER
|
ZED
|
| 23. |
47781338
|
[9] |
SCREW
|
ZED
|
| 24. |
47781291
|
[10] |
COLLAR
|
ZED
|
| 25. |
47781288
|
[10] |
WRAPPER
|
ZED
|
| 26. |
47781343
|
[2] |
WRAPPER
|
ZED
|
| 27. |
47781345
|
[1] |
PLATE
|
ZED
|
| 28. |
47781350
|
[1] |
STRAP
|
ZED
|
| 29. |
47781400
|
[1] |
SUPPORT
|
ZED
|
| 30. |
47781395
|
[1] |
PLATE
|
ZED
|
| 31. |
47781390
|
[1] |
SUPPORT
|
ZED
|
| 32. |
47781385
|
[2] |
SUPPORT
|
ZED
|
| 33. |
47781383
|
[1] |
PLATE
|
ZED
|
| 34. |
47781376
|
[8] |
SCREW
|
ZED
Superseded by part number: 47441864
|
| 35. |
47781172
|
[8] |
WASHER
|
ZED
Superseded by part number: 47441865
|
| 36. |
47781241
|
[8] |
NUT
|
ZED
|
| 37. |
47781373
|
[5] |
TUBE
|
ZED
|
| 38. |
47781370
|
[1] |
TUBE
|
ZED
|
| 39. |
47781363
|
[7] |
NOZZLE
|
ZED
|
| 40. |
47781360
|
[1] |
ADAPTER
|
ZED
|
| 41. |
47781352
|
[1] |
HYD CONNECTOR
|
ZED
|
| 42. |
47441875
|
[6] |
SWIVEL CONNECTION
|
ZED
|
| 43. |
47781337
|
[1] |
COUPLING
|
ZED
|
| 44. |
47781302
|
[4] |
PIPE
|
ZED
|
| 45. |
47781296
|
[1] |
RIVET
|
ZED
|
| 46. |
47781219
|
[1] |
VALVE
|
ZED
|
| 47. |
47781224
|
[1] |
RING
|
ZED
|
| 48. |
47781223
|
[1] |
SCREW
|
ZED
|
| 49. |
47781933
|
[1] |
HYDRAULIC HOSE
|
ZED
|
