神钢零件查询(K909LC) - MARK II EXCAVATOR ASN LLU-0001 (1/87-12/03) (11-022) - CYLINDER ASSY (BUCKET), 2438U908 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
472 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U908F1 | [1] | CYLINDER | KOBASSY, CONSISTS OF THE FOLLOWING PARTS |
| 1. | 2438U908S1 | [1] | TUBE | KOB |
| 2. | 2438U515S2 | [2] | BUSHING | KOB |
| 3. | 2438U697S10 | [4] | SEAL | KOBDUST Superseded by part number: 2445R138D3 |
| 4. | 2438U897S4 | [1] | PISTON ROD | KOB |
| 5. | 2438U908S5 | [1] | PISTON | KOBPISTON |
| 6. | 2438U504S7 | [1] | SEAL | KOBSLIPPER |
| 7. | 2438U504S8 | [1] | O-RING | KOB |
| 8. | R45T0098D1 | [2] | PISTON RING | KOB |
| 9. | 2438U897S9 | [1] | NUT | KOB |
| 10. | 2438U897S10 | [1] | AIR CONDITIONER | KOB |
| 11. | ZD12G10000 | [1] | O-RING,99.40mm ID x 105.60mm OD x 3.10mm | KOBID 99.40 ± 0.85 x OD 105mm |
| 12. | ZD12P09000 | [1] | O-RING | KOB |
| 13. | 2438U897S13 | [1] | BACK-UP RING | KOB |
| 14. | 2438U255E15 | [1] | BUSHING | KOB Superseded by part number: 2405U104D065040 |
| 15. | B38K0038E10 | [1] | CLIP | KOBRING, SNAP |
| 16. | R45P0050D6 | [1] | SEAL | KOBSTEP |
| 17. | 45Z91D16 | [1] | O-RING | KOBID 69.22 ± 0.38 OD 79.88mm |
| 18. | 2438U897S18 | [1] | PACKING | KOBROD |
| 20. | ZS23C14055 | [8] | SCREW,Hex Socket Head, M14 x 55mm | KOBM14x2.0x55mm |
| 21. | 2438U897S21 | [1] | CLAMP | KOBBAND |
| 22. | 2438U897S22 | [2] | CLAMP | KOBBAND |
| 23. | ZS13C10035 | [4] | SCREW | KOBM10x1.50x35mm Superseded by part number: ZS18C10035 |
| 24. | ZW22X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 26. | 2438U897S26 | [1] | U-BRACKET | KOBBAND |
| 27. | 2438U908S27 | [1] | SEAL | KOBDUST |
| . . | 2438U897R100 | [1] | REPAIR KIT | KOBCONSISTS OF REF 11 - 13, 16 - 19 Superseded by part number: 2438U897R100P, 2438U897R100P, 2438U974R100, 2438U897R100P, 2438U974R100, 77257525 |
| . . | 2438U897R110 | [1] | REPAIR KIT | KOBCONSISTS OF REF 6 - 8 Superseded by part number: 2438U897R110P |
