凯斯零件查询(LB424S XL) - BALER (11/16-) (88.060.021[01]) - DIA KIT: CUT-OUT CLUTCH KIT - PICK-UP - D085 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
538 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47500362
|
[1] |
DIA KIT, HARVESTER
|
ATT
Incl 2 - 7
|
| 2. |
84294907
|
[1] |
CLUTCH
|
ZED
|
| 3. |
47500358
|
[1] |
SHAFT
|
ZED
|
| 4. |
84348544
|
[1] |
PLATE
|
ZED
|
| 5. |
140046
|
[6] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 6. |
43260
|
[6] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 10.9, Full Thd
|
BHB
|
| 7. |
84470828
|
[1] |
CHAIN
|
ZED
|
| . . |
86557103
|
[1] |
ADHESIVE
|
CAS
Superseded by part number: L24241DS
|
