凯斯零件查询(LB424S XL) - BALER (11/16-) (88.060.029) - DIA KIT: BOTTOM FILLER PLATE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
714 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
48042281
|
[1] |
DIA KIT, HARVESTER
|
COE
Incl 2 - 7
|
| 2. |
48042280
|
[1] |
PLATE
|
ZED
|
| 3. |
48054038
|
[1] |
PLATE
|
ZED
|
| 4. |
445394
|
[28] |
RIVET,Pop, 3/16" x 1/2" OAL
|
ZED
Superseded by part number: 151-573
|
| 5. |
86507486
|
[7] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 6. |
322358
|
[7] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 7. |
9706690
|
[7] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
