神钢零件查询(K909LC) - MARK II EXCAVATOR BTW LL1207 - LL1487 (1/87-12/03) (01-004) - MOTOR ASSY, SWING Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
956 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6349F3 | [1] | HYDRAULIC MOTOR | KOB |
| 1. | 2401N441 | [1] | FINGER ASSY. | KOBSHAFT,PINION Superseded by part number: 77250116, 2410N518 |
| 2. | 2418T17493 | [1] | SLEEVE | KOBSLEEVE |
| 3. | 2418P12239 | [1] | BUSHING | KOB |
| 5. | 25Z804D22 | [1] | ROLLER BEARING | KOBBEARING,ROLLER |
| 6. | 2425R212 | [1] | SPARE PART | HIT Superseded by part number: 2425R170D18 |
| 7. | 2413J356 | [1] | SPIDER | KOBSPIDER |
| 8. | 2413N414F1 | [1] | DIFF. SPIDER | KOBSPIDER |
| 9. | 2410P772 | [4] | SHAFT | KOB |
| 11. | 2401P642 | [1] | SUN GEAR | KOB |
| 12. | 2401P644 | [4] | PINION | KOB |
| 13. | 2401P643 | [4] | PINION | KOB |
| 14. | ZD11G11000 | [1] | O-RING,109.40mm ID x 115.60mm OD x 3.10mm | KOBID 109.40 ± 0.91 x OD 115mm |
| 15. | ZS23C12035 | [12] | SCREW,Hex Socket Head, M12 x 35mm | KOBM12x1.75x35mm |
| 17. | 2418T17492 | [1] | SPACER | KOB |
| 18. | 2418T17491 | [2] | SPACER | KOB |
| 19. | 2401P645 | [1] | SUN GEAR | KOB |
| 20. | 2418R2D30 | [4] | SNAP RING | KOB |
| 21. | 2438T17496 | [8] | WASHER,THRUST | |
| 22. | 2418T17495 | [8] | THRUST WASHER | KOB |
| 23. | 2418T7513 | [4] | LOCKING PLATE | KOB |
| 24. | ZS23C08014 | [8] | SCREW,Hex Socket Head, M8 x 14mm | KOBM08x1.25x14mm |
| 25. | ZR16X10000 | [1] | RING | KOBRetaining -- ID 94.50 x OD 119 x Th 3.0mm |
| 26. | ZS83C20020 | [2] | SCREW | KOBSet -- M20x2.50x20mm |
| 27. | 2418T17424 | [1] | SPACER | |
| 28. | 2418T17425 | [1] | PIPE | PIPE |
| 29. | ZE72X06000 | [1] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400) |
| 30. | 2418T17590 | [1] | SPACER | KOB |
| 32. | 2420T4530 | [3] | SCREW,M14 x 2 x 185mm | KOBM14x2.0x185mm |
| 33. | ZS23C14150 | [13] | SCREW,Hex Socket Head, M14 x 150mm | KOBM14x2.0x150mm |
| 37. | 2441U756F1 | [1] | MOTOR, SWING | MOTOR, SWING |
| 37-1. | 2436U1241F1 | [1] | CONTROL VALVE | KOB |
| 37-2. | 2441U741F1 | [1] | MOTOR | KOB |
| 37-3. | 2436U1283F2 | [1] | VALVE PRESSURE RELIE | KOB |
| 37-4. | ZS23C12110 | [8] | SCREW,Hex Socket Head, M12 x 110mm | KOBM12x1.75x110mm Superseded by part number: ZS28C12110 |
| 37-5. | ZD12G03500 | [2] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 38. | 2414J1092 | [1] | HOUSING HOUSING | HOUSING HOUSING |
| 39. | 2401N449 | [1] | GEAR | KOB |
| 40. | 2418R237 | [1] | SEAL KIT | KOBOIL |
| 50. | 2418T18166 | [1] | SPACER | KOB |
| 51. | 2414T2990 | [1] | COVER | COVER |
| . . | 24100J9351F1 | [1] | REDUCTION UNIT CONSISTS OF ITEM (SERVICE KIT)1 TO 3.5 TO 9,ll TO l5,17 TO 29, 33,38 TO 40,50,51 | REDUCTION UNIT CONSISTS OF ITEM (SERVICE KIT)1 TO 3.5 TO 9,ll TO l5,17 TO 29, 33,38 TO 40,50,51 |
