神钢零件查询(K909LC) - MARK II EXCAVATOR BTW LL1207 - LL1487 (1/87-12/03) (01-003) - COUNTER WEIGHT ASSY, 24100P1730F5 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
677 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100P1730F5 | [1] | COUNTER-WEIGHT ASSY | |
| 5. | R20T0040D12 | [4] | SCREW | KOB |
| 6. | ZW13H30000 | [4] | WASHER | KOB |
| 9. | 24100P1734F3 | [1] | COUNTER-WEIGHT ASSY | |
| 9-1. | 2422J1883 | [1] | COUNTER-WEIGHT | |
| 9-6. | 2479T1722 | [1] | INSULATION, SOUND | INSULATION, SOUND |
| 18. | 2418T12306D2 | [2] | SHIM | KOB |
| 19. | 2418T12306D3 | [2] | SHIM | KOB |
| 20. | 2418T12306D6 | [2] | SHIM | KOB |
