凯斯零件查询(LB424S XL) - BALER (11/16-) (90.105.065) - TWINE BOXES RH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
914 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47948747
|
[1] |
TWINE BOX
|
ZED
|
| 2. |
84582390
|
[2] |
PLATE
|
ZED
|
| 3. |
86619060
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 16mm, Cl 8.8
|
NH
|
| 4. |
322358
|
[6] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 5. |
9706690
|
[6] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 6. |
140045
|
[3] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 7. |
84607251
|
[1] |
RUBBER WEATHERSTRIP
|
ZED
Superseded by part number: 84818178
|
| 8. |
401502
|
[1] |
ANTI-SKID STRIP
|
ZED
|
| 9. |
86633356
|
[1] |
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
|
ZED
|
| 10. |
84212895
|
[1] |
SEAL
|
ZED
|
| 11. |
47984687
|
[1] |
PLATE
|
ZED
|
| 12. |
43127
|
[2] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 13. |
120041
|
[2] |
CARRIAGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 14. |
100016
|
[3] |
NUT,M10 x 1.5, Cl 8
|
NH
|
