凯斯零件查询(LB424S XL) - BALER (11/16-) (90.116.010) - BUMPER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
482 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84345210
|
[1] |
BRACKET
|
ZED
, Serial Range: -C091
|
| 1. |
47521579
|
[1] |
BRACKET
|
ZED
, Start Serial: D092
|
| 1. |
84345208
|
[1] |
BRACKET
|
ZED
, Serial Range: -C091
|
| 1. |
47521581
|
[1] |
BRACKET
|
ZED
, Start Serial: D092
|
| 1. |
47644841
|
[1] |
SUPPORT
|
ZED
|
| 2. |
120044
|
[1] |
CARRIAGE BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 3. |
140046
|
[1] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 4. |
9706685
|
[1] |
NUT,M12 x 1.75, Cl 8
|
NH
|
