凯斯零件查询(LB424S XL) - BALER (11/16-) (90.118.015) - LADDER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
475 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47967255
|
[1] |
|
PLATE
|
| 2. |
47975495
|
[1] |
|
LADDER
|
| 3. |
84605784
|
[1] |
|
LADDER
|
| 4. |
84579586
|
[1] |
MAGNET
|
ZED
|
| 5. |
47981618
|
[1] |
|
PLATE
|
| 6. |
86507486
|
[8] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 7. |
86977726
|
[1] |
BOLT,Hex, M6 x 12mm, Cl 8.8
|
ZED
|
| 8. |
120104
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 9. |
43130
|
[2] |
BOLT,Hex, M8 x 1.25 x 50mm, Cl 8.8
|
NH
|
| 10. |
412649
|
[1] |
BELLEVILLE WASHER,M6 Bolt Size x 18mm OD x 1.4mm Thk
|
ZED
|
| 11. |
86588502
|
[3] |
WASHER,13mm ID x 25mm OD x 3mm Thk
|
ZED
|
| 12. |
86625263
|
[11] |
WASHER,9mm ID x 20mm OD x 1.6mm Thk
|
ZED
|
| 13. |
322358
|
[13] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 14. |
86629542
|
[2] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 15. |
9706690
|
[11] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 16. |
87301462
|
[2] |
CROWN NUT,Crown, M8, Cl6
|
ZED
|
| 17. |
84014502
|
[1] |
INTRODUCTION CAP
|
ZED
|
| 18. |
401502
|
[1] |
ANTI-SKID STRIP
|
ZED
|
| 19. |
43127
|
[1] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
