凯斯零件查询(LB424S XL) - BALER (11/16-) (90.118.100) - LIGHT ARMS, REAR Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
974 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47642579
|
[1] |
PROFILE
|
ZED
|
| 2. |
47642619
|
[1] |
PROFILE
|
ZED
|
| 3. |
746294
|
[2] |
LAMP REFLECTOR
|
NH
Superseded by part number: 80746294, 80746294, BER746294
|
| 4. |
435895
|
[4] |
REFLECTOR,80mm OD, Orange
|
NH
|
| 5. |
120044
|
[4] |
CARRIAGE BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 6. |
140046
|
[4] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 7. |
9706685
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 8. |
84429678
|
[4] |
RIVET
|
ZED
|
| 9. |
322356
|
[4] |
BELLEVILLE WASHER,M5 Bolt Size x 12mm OD x 1.85mm Thk
|
ZED
|
| 10. |
9839002
|
[2] |
EXTERNAL REFLECTOR
|
ZED
|
| 11. |
47458243
|
[2] |
PLATE
|
PLO
|
| 12. |
47975306
|
[2] |
PLATE
|
ZED
|
| 13. |
140040
|
[4] |
WASHER,6.6mm ID x 22mm OD x 2mm Thk
|
ZED
|
| 14. |
120100
|
[4] |
BOLT,M6 x 20mm, Cl 8.8
|
NH
|
| 15. |
86588450
|
[4] |
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
|
ZED
|
| 16. |
353308
|
[4] |
NUT,M6 x 1.0, Cl 8
|
NH
|
