凯斯零件查询(LB433R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (03.09[01]) - MAIN GEARBOX, ARM SHAFT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
631 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84074505
|
[2] |
SEALING RING
|
ZED
SEALRING
|
| 2. |
84000814
|
[2] |
ROLLER BEARING,140mm ID x 210mm OD x 45mm W
|
ZED
|
| 3. |
87718403
|
[1] |
SPACER
|
ZED
|
| 4. |
84074491
|
[1] |
GEAR
|
ZED
|
| 5. |
87718402
|
[1] |
SHAFT
|
ZED
|
| 6. |
84074501
|
[1] |
SET OF RINGS
|
ZED
|
| 7. |
87688201
|
[2] |
COVER
|
ZED
|
| 8. |
87688225
|
[2] |
O-RING,209.1mm ID x 3.53mm Width
|
ZED
|
| 9. |
412123
|
[16] |
LOCK WASHER,13.1mm ID x 21.1mm OD x 2.55mm Thk
|
NH
|
| 10. |
300389
|
[16] |
BOLT,M12 x 1.75 x 35mm, Cl 8.8
|
NH
, Serial Range: -C719 Superseded by part number: 628-12035
|
| 10. |
379753
|
[16] |
BOLT,Hex, M12 x 35mm, Cl 10.9
|
PA
, Start Serial: D720 Superseded by part number: 626-12035
|
