凯斯零件查询(LB433R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (03.10[01]) - MAIN GEARBOX, ARM TO PLUNGER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
120 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84074507
|
[1] |
CAP
|
ZED
|
| 2. |
412270
|
[2] |
SNAP RING,M120 x 4mm Thk, Internal
|
ZED
|
| 3. |
84074500
|
[2] |
CIRCLIP
|
ZED
|
| 4. |
84074503
|
[2] |
BALL BEARING,65 mm ID x 120 mm OD x 31 mm
|
ZED
|
| 5. |
80300919
|
[2] |
LUBE NIPPLE,M8 x 1
|
ZED
Superseded by part number: 84447449
|
| 6. |
84074493
|
[2] |
HUB
|
ZED
Superseded by part number: 84296753
|
| 7. |
84074502
|
[2] |
THRUST WASHER,100.5mm ID x 119.5mm OD x 1mm Thk
|
ZED
|
| 8. |
84074504
|
[2] |
SEALING RING
|
ZED
SEALRING
|
| 9. |
84819391
|
[1] |
ARM
|
ZED
RH
|
| 10. |
84074497
|
[4] |
BOLT,Hex, M22 x 170mm
|
ZED
|
| 11. |
84074498
|
[4] |
WASHER
|
ZED
22 MM
|
| 12. |
84074506
|
[1] |
SEALING RING
|
ZED
SEALRING
|
| 13. |
84819392
|
[1] |
ARM
|
ZED
LH
|
| 14. |
84800768
|
[2] |
WASHER
|
ZED
|
| 15. |
86629541
|
[4] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 16. |
80412123
|
[4] |
LOCK WASHER
|
ZED
Superseded by part number: 412123
|
| 17. |
84819393
|
[1] |
ARM
|
ZED
(1 to 11, 14 to 16) RH
|
| 18. |
84819394
|
[1] |
ARM
|
ZED
(2 to 8, 10 to 16) LH
|
