纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (05-002) - CONTROL LINES, REMOTE (BOOM SAFETY) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
361 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY64H00037F1 | [1] | CONTROL LINES, VALVE | |
| 1. | YY64H01020P1 | [1] | BRACKET | KOB |
| 2. | ZH22X06000 | [1] | HYD CONNECTOR | KOB |
| 3. | ZH32X06000 | [1] | 90 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 5. | 2444R596D3 | [1] | ELBOW | KOB |
| 6. | ZE72X06000 | [5] | PLUG | KOB |
| 7. | YV64H01024P1 | [1] | BLOCK | KOB |
| 8. | 2418Z1333D35 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 1800mm Length | KOBProtective Plastic |
| 10. | YN20M01046D6 | [1] | TUBE,22.10mm ID x 27.00mm OD x 1900.00mm | KOBProtective Plastic |
| 11. | ZX22M08170 | [1] | HOSE | KOB |
| 12. | ZX22M08200 | [1] | HOSE | KOB |
| 13. | ZX23M06200 | [1] | FLEXIBLE HOSE | KOB |
| 14. | ZX23M06175 | [1] | HOSE | KOB |
| 18. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOB |
| 21. | ZW16H08000 | [2] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 22. | ZW16H10000 | [2] | WASHER | KOB |
| 23. | YN20M01046DT | [1] | TUBE,22.10mm ID x 27.00mm OD x 1500.00mm | KOBProtective Plastic |
| 24. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOB |
| 25. | 2418Z1333D5 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 400mm Length | KOB |
| 26. | PY01P01043D5 | [1] | CABLE TIE,301mm L | KOB |
| 27. | PY01P01043D8 | [1] | CABLE TIE,102mm L | KOB |
| 30. | 2444R399D9 | [2] | HYD CONNECTOR | KOBELBOW |
