纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (05-011) - HYD LINES, BOOM 4.26 M (BOOM SAFETY) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
136 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YV01V00001F1 | [1] | CYLINDER | KOBASSY, BOOM (L.H) YV04-03043 to YV04 -03176 Superseded by part number: YV01V00001F2 |
| 1. | YV01V00001F2 | [1] | CYLINDER | KOBCYLINDER ASSY, BOOM (L.H) YV04-03177 to |
| 2. | YV01V00002F2 | [1] | CYLINDER ASSY, BOOM (R.H) YV04-03177 to | |
| . . | YV42H00035F1 | [1] | HYD LINES, CYLINDER | |
| 1. | YV42H01009P1 | [1] | RIGID TUBE | KOB |
| 2. | YV42H01010P1 | [1] | RIGID TUBE | KOB |
| 3. | YY42H01102P1 | [2] | TUBE | KOB |
| 4. | ZX20H10074 | [4] | HOSE | KOB |
| 5. | ZX20H10125 | [1] | FLEXIBLE HOSE | HIT |
| 6. | ZX23M06140 | [1] | HOSE | KOB |
| 7. | ZX22M08140 | [1] | HOSE | KOB |
| 10. | ZH22X06000 | [1] | HYD CONNECTOR | KOB |
| 11. | HH25R06006GE | [2] | ELEC CONNECTOR | KOB |
| 12. | ZG23F10008 | [1] | HYD CONNECTOR | KOB |
| 13. | ZH22Z04000 | [2] | HYD CONNECTOR | KOB |
| 14. | 2444Z3399 | [1] | HYD CONNECTOR | KOB |
| 15. | 2444Z3155 | [1] | 90 ELBOW,PF 3/8" Fem x PF 3/8" Male | KOB Superseded by part number: YT42H01128P1 |
| 16. | 2444R596D2 | [1] | ELBOW | KOB |
| 17. | HG33H10012G1 | [2] | ELBOW | KOB |
| 18. | 2444R399D9 | [1] | HYD CONNECTOR | KOB |
| 19. | 2444R596D3 | [1] | ELBOW | KOB |
| 20. | 2444Z2359 | [1] | TEE | KOB |
| 21. | 2444Z3945 | [1] | TEE | KOB |
| 22. | ZG91S02000 | [2] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOBGREASE |
| 23. | 2432T2244 | [2] | CLAMP | KOB |
| 24. | ZS18C10045 | [2] | SCREW,Hex, M10 x 45mm | KOBCAP |
| 25. | ZS28C10030 | [8] | SCREW,Hex Socket Head, M10 x 30mm | KOBCAP |
| 26. | ZS28C10060 | [8] | SCREW,Hex Socket Head, M10 x 60mm | KOBCAP |
| 27. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 28. | ZD12A01600 | [8] | O-RING | KOB |
| 29. | ZD12P02600 | [4] | O-RING | KOB |
| 30. | 2432Z290 | [10] | CLIP | KOB Superseded by part number: PY01P01043D3 |
| 31. | YN50S00031F1 | [1] | PRESSURE SWITCH | KOBOIL |
| 32. | YY42H01411P1 | [1] | PLATE | KOB |
| 33. | YY42H01324P1 | [1] | PLATE | KOB |
| 34. | 2432T1232 | [1] | CLAMP | KOB |
| 35. | 2444Z3713 | [1] | HYD CONNECTOR | KOB |
| 36. | HG23F04004G1 | [1] | HYD CONNECTOR | KOB |
| 37. | HG33H04004G1 | [1] | ELBOW | KOB |
| 38. | YN42H01602P1 | [1] | TEE | KOB |
| 39. | ZS18C05040 | [2] | CAPSCREW,Hex, M5 x 40mm | KOBSCREW CAP |
| 40. | ZS18C08025 | [2] | SCREW,Hex, M8 x 25mm | KOBCAP |
| 41. | ZS18C10065 | [2] | SCREW,Hex, M10 x 65mm | KOBCAP |
| 42. | ZN18C10008 | [2] | NUT | KOBM10x1.50mm |
| 43. | ZW16H08000 | [2] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 44. | ZW16H10000 | [2] | WASHER | KOB |
| 45. | ZW26X05000 | [2] | LOCK WASHER | KOBLOCK |
| 46. | YY42H01330P1 | [1] | O-RING,0.07" Thk x 0.301" ID, -11, Cl 5, 75 Duro | KOB |
