纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (05-013) - HYD LINES, BOOM 4.26 M (BOOM & ARM SAFETY) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
729 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YV42H00023F1 | [1] | HYD LINES, BOOM 4.26M | |
| 1. | ZX22M08390 | [1] | FLEXIBLE HOSE | KOB |
| 2. | ZX23M06380 | [1] | FLEXIBLE HOSE | KOB |
| 3. | 2414Z199D050 | [1] | GUIDE | KOBHOSE, GUARD |
| 4. | LF42H01009P1 | [1] | BRACKET | KOB |
| 5. | 2444R402D4 | [2] | HYD CONNECTOR | HIT |
| 6. | ZH22X06000 | [2] | HYD CONNECTOR | KOB |
| 7. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBCap |
| 8. | ZS18C10016 | [1] | SCREW,Hex, M10 x 16mm | KOBM10x1.50x16mm |
| 9. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 10. | ZW16H10000 | [1] | WASHER | KOB |
| 11. | ZC46X46014 | [1] | CLIP | KOB |
| 12. | PY01P01043D5 | [20] | CABLE TIE,301mm L | KOB |
