纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (02-001) - LOW GROUP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
835 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | YX15V00003F4 | [2] | MOTOR | KOBASSY, HYD |
| . . | YX15V00003F4R | [2] | REMAN-HYD MOTOR | KOBE115SR ASN YV04-03043 |
| . . | YX15V00003F4C | [1] | CORE-MOTOR HYDRAULIC | KOBReturn Number |
| A1. | YV02F00038P1 | [1] | FRAME, LOW | |
| A1-1. | YV07F01045P1 | [2] | SUPPORT | KOB(FOR IRON) YV04-03043, Serial Range: -YV04-03713 |
| A1-1. | YY07F01117P1 | [2] | SUPPORT | KOBSUPPORT YV04-03714 to |
| A1-2. | YY41C00005P1 | [4] | STEP | KOB |
| A1-3. | YY07F01012P1 | [2] | GUIDE | KOB(LH) |
| A1-4. | YY07F01013P1 | [2] | GUIDE | KOB(R.H) |
| A2. | YV02F00039P1 | [1] | FRAME, LOW (FOR RUBBER) | |
| . . | YV01F00005F1 | [1] | LOW GROUP | |
| B1. | YV01F01007P1 | [2] | COVER | KOB |
| B2. | YV63D00001P1 | [2] | GUIDE | KOBTRACK |
| B3. | 2422T556 | [1] | PLATE | KOB |
| B4. | 2418T12274 | [1] | PACKING | KOBRUBBER |
| B5. | ZS18C18040 | [8] | SCREW,Hex, M18 x 40mm | KOBM18x2.50x40mm |
| B6. | ZW16H18000 | [8] | WASHER | KOBID 19 x OD 36 x Th 4.5mm |
| B7. | ZS18C12025 | [8] | SCREW,Hex, M12 x 25mm | KOBCAP, Serial Range: YV04-03043-YV04-03339 |
| B8. | ZS18C10014 | [2] | SCREW,Hex, M10 x 14mm | KOBCAP |
| B9. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| B10. | ZW16X12000 | [8] | WASHER | KOB, Serial Range: YV04-03043-YV04-03339 |
| B11. | ZW26X12000 | [8] | WASHER | KOB, Serial Range: YV04-03043-YV04-03339 |
| B12. | ZM73C12025 | [8] | BOLT,M12x25mm - Course Thread | KOBSEMS YV04-03340 to |
| . . | YN19H00040F2 | [1] | FLEXIBLE JOINT | KOBINSTAL, SWIVEL |
| C3. | ZS18F20120 | [1] | SCREW | KOBCAP |
| C5. | ZN18F20016 | [1] | NUT | KOB |
| C6. | YN55V00037F2 | [1] | FLEXIBLE JOINT | KOBASSY, SWIVEL |
| . . | YV53D00002F1 | [1] | MOTOR | KOBINSTAL, PROPEL |
| D1. | 2404N271 | [2] | SPROCKET,21 T, 324mm ID x 601mm OD | KOB |
| D2. | LP53D01001P1 | [70] | BOLT,Hex, M16 x 2 x 45mm | KOBCAP (INSTAL, SPROCKET 30) (INSTAL, PROPEL MOTOR 40) Superseded by part number: LP53D01001P2 |
