凯斯零件查询(LB433R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (06.11[01]) - SIDE LIGHTS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
402 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
449531
|
[2] |
POSITION LAMP,Red
|
ZED
|
| 2. |
353078
|
[2] |
BULB,T8/4, 12V, 4W
|
ZED
Superseded by part number: 3050199R91
|
| 3. |
84073095
|
[2] |
WIRE HARNESS
|
ZED
|
| 4. |
86566990
|
[9] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
CABLE STRAP
|
| 5. |
84818442
|
[22] |
CLAMP,13.3mm ID, 6.7mm Bolt Hole, P Type
|
ZED
|
| 6. |
84818443
|
[1] |
CLAMP,16.3mm ID, 6.7mm Bolt Hole, P Type
|
ZED
|
| 7. |
9512290
|
[12] |
RIVET,Pop, 4.8mm OD x 17.8mm L
|
ZED
|
| 8. |
84459692
|
[1] |
WIRE HARNESS
|
ZED
|
| 9. |
322356
|
[21] |
BELLEVILLE WASHER,M5 Bolt Size x 12mm OD x 1.85mm Thk
|
ZED
|
| 10. |
86508568
|
[4] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8
|
NH
|
| 11. |
322357
|
[8] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 12. |
9706755
|
[4] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
