神钢零件查询(K909LC) - MARK II EXCAVATOR BTW LL1207 - LL1487 (1/87-12/03) (09-003) - ARM ASSY, 2.32M Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
462 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6645F3 | [1] | ARM ASSY, 2.32M | |
| 2. | 2438U959F1 | [1] | CYLINDER | KOBCYLINDER |
| 3. | 2406N808F1 | [1] | LINK, BUCKET | LINK, BUCKET |
| 3-8. | 2405T1263 | [2] | BUSHING | KOB |
| 3-9. | 2405T1264 | [2] | BUSHING | KOB |
| 4. | 2406P2617D1 | [1] | LINK CONROD | KOB |
| 5. | 2406P2617D2 | [1] | LINK CONROD | KOB |
| 6. | 2419P1727 | [1] | PIN | KOB |
| 7. | 2419P1709D2 | [1] | PIN | KOB |
| 8. | 2419P1710D2 | [1] | PIN | KOB |
| 9. | 2419T4684D1 | [2] | PIN,90mm OD x 500mm L | KOB Superseded by part number: 2419T7611D1 |
| 10. | 2419P1679D1 | [1] | PIN | KOB |
| 11. | ZX56N12130 | [2] | HOSE | KOB |
| 12. | 2445R372D2 | [4] | DUST CAP | KOB |
| 13. | 2445R372D1 | [2] | DUST CAP | KOB |
| 14. | 2445R372D4 | [6] | DUST CAP | KOB |
| 15. | ZG91S02000 | [6] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 16. | ZG91V02000 | [1] | LUBE NIPPLE,67 Degree x 1/8" PT | KOB67° x 1/8" PT Superseded by part number: 72283072 |
| 17. | ZD12P02600 | [2] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 18. | 2418T17955 | [1] | RIGID TUBE | KOB |
| 19. | 2418T17956 | [1] | TUBE | KOB |
| 20. | ZS13C16130 | [1] | SCREW | KOB |
| 21. | 2420T4330D2 | [2] | SCREW,M16 x 2 x 150mm | KOBM16x2.0x150mm Superseded by part number: HS18C16150G1 |
| 22. | ZS13C16140 | [1] | SCREW | KOBM16x2.0x140mm |
| 23. | 2411N2159F1 | [1] | ARM | |
| 23-5. | 2418T17900 | [1] | SPACER | KOB |
| 23-6. | 2418T17497 | [1] | SPACER | KOB |
| 23-7. | 2405T1293 | [2] | BUSHING | KOB |
| 23-8. | B05T0041C2 | [2] | BUSHING | KOB |
| 23-9. | 2405T585C2 | [2] | BUSHING | KOB |
| 24. | ZS13C10070 | [8] | SCREW | KOBM10x1.50x70mm Superseded by part number: ZS18C10070 |
| 25. | ZN12C16013 | [8] | NUT | KOBM16x2.0mm |
| 26. | ZS13C10035 | [4] | SCREW | KOBM10x1.50x35mm Superseded by part number: ZS18C10035 |
| 27. | ZN12C06005 | [7] | NUT | KOBM06x1.0mm Superseded by part number: ZN18C06005 |
| 29. | ZW22X10000 | [12] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 31. | ZW22X06000 | [7] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 32. | 2416T3655 | [2] | CLAMP | KOB |
| 33. | ZC45X10009 | [3] | CLIP | KOB Superseded by part number: ZC46X10009 |
| 34. | 2432T1187 | [2] | CLAMP | KOB Superseded by part number: YN43H01097P1 |
| 36. | 2444Z2002 | [4] | HYD CONNECTOR | KOB1/8"PTx1/4"PFx32mm Long |
| 37. | ZH32Z04002 | [1] | ELBOW | KOB90° -- 1/4" PF - 1/8" PT |
| 38. | 2420R349D7 | [1] | HOSE | KOBHOSE Superseded by part number: 2420R349D200 |
| 39. | 2420R349D210 | [1] | FLEXIBLE HOSE | KOB2100mm Long (82-11/16 in) |
| 40. | 2420R349D250 | [1] | HOSE,2500.00 mm | KOB |
| 41. | ZH32Z04000 | [1] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| 42. | 2416T18868 | [1] | BRACKET | KOB |
| 43. | 2416T18869 | [1] | BRACKET | KOB |
| 48. | B16T0442D2 | [1] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOBID 72 x OD 130 x Th 1.6mm |
| 49. | B16T0442D4 | [2] | SHIM,82mm ID x 150mm OD x 1.6mm Thk | KOBID 82 x OD 150 x Th 1.6mm |
| 50. | B16T0442D14 | [1] | SHIM,160mm OD x 92mm ID x 1.6mm Thk | KOBID 92 x OD 160 x Th 1.6mm |
