| 1. |
87752222
|
[1] |
WIRE HARNESS
|
ZED
, Serial Range: -C813 Superseded by part number: 84243503
|
| 1. |
84243503
|
[1] |
WIRE HARNESS
|
ZED
, Start Serial: D814
|
| 2. |
82002966
|
[2] |
POWER SOCKET
|
IMO
, Serial Range: -C751 Superseded by part number: 84191453
|
| 2. |
84191453
|
[2] |
SOCKET,12/24V, 20A
|
DUB
, Start Serial: D752
|
| 3. |
87342073
|
[1] |
SENSOR
|
GI
B8 - SENSOR PICK UP SPEED, Serial Range: -C867
|
| 3. |
87680717
|
[1] |
SENSOR
|
ZED
B8 - SENSOR PICK UP SPEED, Start Serial: D868 Superseded by part number: 84391774
|
| 7. |
84131149
|
[1] |
WIRE HARNESS
|
ZED
|
| 8. |
84460888
|
[1] |
WIRE HARNESS
|
ZED
|
| 9. |
84819755
|
[1] |
PLUG
|
ZED
|
| 10. |
103258
|
[1] |
GROMMET,5/8" ID x 7/8" Groove Dia
|
GI
|
| 11. |
86523197
|
[1] |
SENSOR
|
ZED
B16 - PRESSURE SENSOR (37)
|
| 12. |
129959
|
[2] |
GROMMET
|
NH
|
| 13. |
401310
|
[1] |
PROFILE
|
ZED
L= 320 MM
|
| 14. |
86566989
|
[1] |
CABLE TIE,208mm L
|
ZED
CABLE STRAP
|
| 15. |
86590413
|
[1] |
BASE,15.87mm W x 22.22mm OAL x 9.9mm Thk
|
ZED
, Serial Range: -C751
|
| 15. |
84058832
|
[1] |
CLIP
|
ZED
, Start Serial: D752
|
| 16. |
445394
|
[1] |
RIVET,Pop, 3/16" x 1/2" OAL
|
ZED
Superseded by part number: 151-573
|
| 17. |
9512290
|
[1] |
RIVET,Pop, 4.8mm OD x 17.8mm L
|
ZED
|
| 18. |
9512289
|
[5] |
RIVET,Pop, 4.8mm OD x 20.7mm L
|
PLO
|
| 19. |
9837759
|
[1] |
CLAMP,7mm ID, 10.5mm Bolt Hole, P Type
|
ZED
, Serial Range: -C867
|
| 20. |
86010402
|
[5] |
CLAMP,12.7mm, Coat, 10.3mm Bolt Hole, P Type
|
NH
|
| 21. |
84818442
|
[1] |
CLAMP,13.3mm ID, 6.7mm Bolt Hole, P Type
|
ZED
|
| 22. |
84818444
|
[3] |
CLAMP,22.3mm ID, 6.7mm Bolt Hole, P Type
|
ZED
|
| 23. |
9837692
|
[2] |
CLAMP,16.67mm ID, 13.46mm Bolt Hole, P Type
|
ZED
|
| 24. |
418407
|
[4] |
CLAMP,24mm ID, 8.5mm Bolt Hole, P Type
|
ZED
|
| 25. |
84818441
|
[1] |
CLAMP,12.3mm ID, 6.7mm Bolt Hole, P Type
|
ZED
|
| 26. |
43117
|
[1] |
SCREW,Hex, M6 x 1.0 x 30mm, Cl 8.8
|
NH
Superseded by part number: 87317695
|
| 27. |
322357
|
[1] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 28. |
9706755
|
[1] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 29. |
9824326
|
[1] |
WASHER,5.3mm ID x 10mm OD x 1mm Thk
|
NH
|
| 30. |
9706690
|
[4] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 31. |
322358
|
[3] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 32. |
9839372
|
[1] |
CLAMP,11.1mm, Coat, 10.3mm Bolt Hole, P Type
|
ZED
|
| 33. |
43127
|
[3] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 34. |
80401310
|
[1] |
PROFILE
|
ZED
L= 150 MM, Serial Range: -C813 Superseded by part number: 401310
|
| 34. |
291186
|
[1] |
PROTECTION STRIP,9.9mm W
|
NH
L= 150 MM, Start Serial: D814 Superseded by part number: 47560081, 47560080
|
| 35. |
381014
|
[1] |
SCREW,Flng, M8 x 16mm
|
NH
, Start Serial: D814
|
| 37. |
84320139
|
[1] |
O-RING,2.2mm Thk x 11.3mm ID
|
ZED
|
