| 1. |
87754263
|
[1] |
WIRE HARNESS
|
ZED
|
| 1. |
87754265
|
[1] |
WIRE HARNESS
|
ZED
|
| 2. |
82002966
|
[2] |
POWER SOCKET
|
IMO
, Serial Range: -C751 Superseded by part number: 84191453
|
| 2. |
84191453
|
[2] |
SOCKET,12/24V, 20A
|
DUB
, Start Serial: D752
|
| 3. |
87342073
|
[1] |
SENSOR
|
GI
B12 - SENSOR NEEDLE CARRIAGE, Serial Range: -C867
|
| 3. |
87680717
|
[1] |
SENSOR
|
ZED
B12 - SENSOR NEEDLE CARRIAGE, Serial Range: -F868868 Superseded by part number: 84391774
|
| 5. |
87374580
|
[1] |
WIRE HARNESS
|
ZED
|
| 6. |
87375051
|
[1] |
COVER
|
ZED
|
| 7. |
87342069
|
[1] |
SENSOR
|
ZED
B7 - REF SPEED SENSOR, Serial Range: -C867
|
| 7. |
87680718
|
[1] |
SENSOR
|
ZED
B7 - REF SPEED SENSOR, Serial Range: -F868868 Superseded by part number: 87342069
|
| 8. |
84078760
|
[4] |
SENSOR
|
ZED
B2 B3 B4 B5 - SENSOR MISTIE
|
| 9. |
129959
|
[1] |
GROMMET
|
NH
|
| 10. |
86566989
|
[1] |
CABLE TIE,208mm L
|
ZED
CABLE STRAP
|
| 11. |
86590413
|
[1] |
BASE,15.87mm W x 22.22mm OAL x 9.9mm Thk
|
ZED
, Serial Range: -C751
|
| 11. |
84058832
|
[1] |
CLIP
|
ZED
, Start Serial: D752
|
| 12. |
445394
|
[1] |
RIVET,Pop, 3/16" x 1/2" OAL
|
ZED
Superseded by part number: 151-573
|
| 13. |
9512290
|
[1] |
RIVET,Pop, 4.8mm OD x 17.8mm L
|
ZED
|
| 14. |
87601142
|
[1] |
ELEC CONNECTOR,Female, 6 Cavities
|
PLO
|
| 15. |
9837625
|
[1] |
CLAMP,25.4mm ID, 10.5mm Bolt Hole, P Type
|
ZED
|
| 16. |
86010402
|
[2] |
CLAMP,12.7mm, Coat, 10.3mm Bolt Hole, P Type
|
NH
|
| 17. |
84818442
|
[1] |
CLAMP,13.3mm ID, 6.7mm Bolt Hole, P Type
|
ZED
|
| 18. |
84818444
|
[1] |
CLAMP,22.3mm ID, 6.7mm Bolt Hole, P Type
|
ZED
|
| 19. |
84818443
|
[1] |
CLAMP,16.3mm ID, 6.7mm Bolt Hole, P Type
|
ZED
|
| 20. |
396718
|
[3] |
STRAP
|
ZED
Superseded by part number: 529070
|
| 21. |
86511816
|
[4] |
SCREW,Pan, M3 x 0.5 x 16mm, Cl 4.8
|
ZED
|
| 22. |
412548
|
[8] |
WASHER,3.2mm ID x 7mm OD x 0.5mm Thk
|
ZED
|
| 23. |
86508812
|
[4] |
NUT,M3, Cl 8
|
ZED
Superseded by part number: 1175064
|
| 24. |
9824326
|
[1] |
WASHER,5.3mm ID x 10mm OD x 1mm Thk
|
NH
|
| 25. |
9706690
|
[1] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 26. |
322358
|
[1] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 27. |
378243
|
[1] |
WASHER,8.4mm ID x 21mm OD x 1.6mm Thk
|
NH
Superseded by part number: 63707, 63707, 86625263
|
| 28. |
452802
|
[1] |
GROMMET
|
ZED
, Start Serial: D814
|
| 29. |
9839372
|
[1] |
CLAMP,11.1mm, Coat, 10.3mm Bolt Hole, P Type
|
ZED
, Start Serial: D814
|
| 30. |
120098
|
[1] |
BOLT,Hex, M5 x 20, 8.8, Full Thd
|
NH
, Start Serial: D814
|
| 31. |
412618
|
[1] |
WASHER,6.4mm ID x 18mm OD x 1.6mm Thk
|
ZED
, Start Serial: D814
|
| 32. |
322356
|
[1] |
BELLEVILLE WASHER,M5 Bolt Size x 12mm OD x 1.85mm Thk
|
ZED
, Start Serial: D814
|
| 33. |
43440
|
[1] |
LOCK NUT,M5 x .8, Cl 8
|
NNA
, Start Serial: D814 Superseded by part number: 80043440, 80043440, A48168, 80043440, A48168, NLS
|
