纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (02-012) - TRACK ROLLER ASSY, P/N YY64D00018F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
764 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY64D00018F1 | [1] | TRACK ROLLER | KOBROLLER ASSY, TRACK (STD) |
| 1. | YY64D00022F1 | [12] | ROLLER, TRACK | KOBROLLER ASSY, TRACK, LOW |
| 1-1. | 2413N413 | [1] | ROLLER | KOB |
| 1-2. | YY64D01019P1 | [1] | SHAFT | |
| 1-3. | 2405P490 | [2] | BUSHING | KOB |
| 1-4. | YY64D01018P1 | [2] | PIN | KOBPIN |
| 1-5. | 2445R440F1 | [2] | SEAL,73mm ID x 96.8mm OD x 33mm Thk | KOBASSY, FLOATING |
| 1-6. | ZD11G04500 | [2] | O-RING,44.40mm ID x 50.60mm OD x 3.10mm | KOB |
| 1-7. | YY64D01016P1 | [2] | COLLAR | |
| 1-8. | ZE82T04000 | [2] | PLUG | KOB |
| 2. | LP64D01004P1 | [48] | SCREW | KOBCAP |
