纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (02-015) - ROLLER ASSY, UPP P/N YY64D00003F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
506 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY64D00003F1 | [1] | ROLLER | KOBASSY, UPP |
| 1. | YY64D01005F1 | [2] | ROLLER | KOBASSY |
| 1-1. | LP64D01009P1 | [1] | ROLLER | KOB |
| 1-2. | YY64D01004P1 | [1] | SHAFT | KOB |
| 1-3. | 2418P23223 | [1] | COLLAR | KOB |
| 1-4. | LP64D01008P1 | [1] | PLATE | KOB |
| 1-5. | 2414T4769 | [1] | COVER | KOB |
| 1-6. | 2405T980 | [1] | BUSHING | KOB |
| 1-7. | 2445R360F1 | [1] | SEAL KIT,45mm ID x 62.2mm OD x 22.8mm Thk | KOBASSY, FLOATING |
| 1-8. | ZD11G05500 | [1] | O-RING,54.40mm ID x 60.60mm OD x 3.10mm | KOB |
| 1-9. | LP64D01010P1 | [2] | BOLT | KOB |
| 1-10. | ZR26X06000 | [1] | RING | KOBRETAINING |
| 1-11. | ZE82T04000 | [1] | PLUG | KOB |
| 2. | ZS13C20110 | [2] | CAPSCREW | KOBSCREW CAP |
| 3. | ZN13C20016 | [2] | NUT | KOB |
| 4. | ZW13H20000 | [4] | WASHER | KOB |
