纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (02-022) - HYDRAULIC LINES, LOW P/N YV02H00006F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
312 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YV02H00006F1 | [1] | HYD LINES, LOW | |
| A1. | YY02H01103P1 | [1] | TUBE | KOB |
| A2. | YY02H01104P1 | [1] | TUBE | KOB |
| A3. | YY02H01105P1 | [1] | TUBE | KOB |
| A4. | YY02H01106P1 | [1] | TUBE | KOB |
| A5. | YY02H01107P1 | [1] | TUBE | KOB |
| A6. | YY02H01108P1 | [1] | TUBE | KOB |
| A7. | YV02H01055P1 | [1] | RIGID TUBE | KOB |
| A8. | YV02H01056P1 | [1] | RIGID TUBE | KOB |
| A9. | YV02H01057P1 | [1] | RIGID TUBE | KOB |
| A10. | YV02H01058P1 | [1] | RIGID TUBE | KOB |
| A12. | YV02H01060P1 | [1] | RIGID TUBE | KOB |
| A14. | LP02H01075P1 | [2] | CLAMP | KOB |
| A15. | ZA23B22000 | [4] | HYD CONNECTOR | KOB |
| A16. | ZA23B18000 | [2] | HYD CONNECTOR | KOB |
| A17. | LP02H01074P1 | [2] | CLAMP | KOB |
| A18. | YW02H01074P1 | [4] | SPACER | KOB |
| A19. | ZW16X08000 | [4] | WASHER | KOB |
| A20. | ZW26X08000 | [4] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| A21. | ZS18C08040 | [4] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| A22. | 2420Z1224D4 | [4] | HOSE | KOBGUARD |
| A23. | PY01P01043D3 | [10] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| . . | YV19H00002F1 | [1] | LINE | KOBHYD, SWIVEL |
| B1. | 2444Z2320 | [4] | ELEC CONNECTOR | KOB |
| B2. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB |
| B2-1. | ZD12P01100 | [1] | O-RING | KOB |
| B3. | ZA23F18008 | [2] | HYD CONNECTOR | KOB |
| B4. | ZD12P02900 | [4] | O-RING | KOB |
| B5. | ZD12P01800 | [2] | O-RING | KOB |
| . . | YV12H00003F1 | [1] | LINE | KOBHYD, PROPEL |
| C1. | ZA24F22012 | [4] | ELEC CONNECTOR | KOB |
| C4. | ZD12P02400 | [4] | O-RING | KOB |
