纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (02-023) - HYD LINES, LOW (FOR LONG CRAWLER) P/N YY02H00047F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
852 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY02H00047F1 | [1] | HYD LINES, LOW | |
| A1. | YV02H01025P1 | [1] | TUBE | KOB |
| A2. | YV02H01026P1 | [1] | TUBE | KOB |
| A3. | YV02H01027P1 | [1] | TUBE | KOB |
| A4. | YV02H01028P1 | [1] | TUBE | KOB |
| A5. | YY02H01170P1 | [1] | TUBE | KOB |
| A6. | YY02H01171P1 | [1] | TUBE | KOB |
| A7. | YY02H01204P1 | [1] | TUBE | KOBTUBE |
| A8. | YY02H01205P1 | [1] | TUBE | KOBTUBE |
| A9. | YY02H01206P1 | [1] | TUBE | KOBTUBE |
| A10. | YY02H01207P1 | [1] | TUBE | KOBTUBE |
| A11. | YY02H01208P1 | [1] | TUBE | KOBTUBE |
| A12. | YY02H01209P1 | [1] | TUBE | KOBTUBE |
| A13. | ZX23M04200 | [2] | HOSE ASSY. | KOB |
| A14. | 2420Z1224D4 | [2] | HOSE | KOBGUARD |
| A15. | PY01P01043D3 | [12] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| A16. | ZA23B22000 | [6] | HYD CONNECTOR | KOB |
| A17. | YV02H01021P1 | [2] | CLAMP | KOB |
| A18. | YV02H01022P1 | [2] | CLAMP | KOB |
| A19. | ZS28C10040 | [4] | CAP,Hex Socket Head, M10 x 40mm | KOBSCREW |
| A20. | ZW26K10000 | [4] | LOCK WASHER | KOBLOCK |
| . . | YV19H00002F1 | [1] | LINE | KOBHYD, SWIVEL |
| B1. | 2444Z2320 | [4] | ELEC CONNECTOR | KOB |
| B2. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB |
| B2-1. | ZD12P01100 | [1] | O-RING | KOB |
| B3. | ZA23F18008 | [2] | HYD CONNECTOR | KOB |
| B4. | ZD12P02900 | [4] | O-RING | KOB |
| B5. | ZD12P01800 | [2] | O-RING | KOB |
| . . | YV12H00002F1 | [1] | LINE | KOBHYD, PROPEL |
| C1. | ZA23F22012 | [4] | HYD CONNECTOR | KOB |
| C2. | ZA23F22008 | [2] | HYD CONNECTOR | KOB |
| C4. | ZD12P02400 | [4] | O-RING | KOB |
