纽荷兰零件查询(E115SR) - CRAWLER EXCAVATOR ASN YV04-03043 (01-004) - ENGINE INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
264 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY02P00008F1 | [1] | ENGINE | KOBINSTAL |
| 1. | YW02P01002P2 | [2] | ENGINE MOUNT | KOBRUBBER |
| 2. | YW02P01003P2 | [2] | ENGINE MOUNT | KOBRUBBER |
| 3. | YW02P01004P1 | [4] | ENGINE MOUNT | KOBRUBBER |
| 4. | ZS18C18090 | [2] | CAPSCREW,Hex, M18 x 90mm | KOBSCREW CAP |
| 5. | ZS18C18130 | [1] | SCREW,Hex, M18 x 130mm | KOBM18x2.50x130mm |
| 6. | HS18C18220G1 | [1] | SCREW | KOBCAP |
| 7. | ZN18C18015 | [4] | NUT | KOB |
| 8. | ZW16X18000 | [2] | WASHER | KOB |
| 9. | YV02P01004P1 | [2] | PLATE | KOB |
| 10. | YY02P01004P1 | [1] | BRACKET | KOB |
| 12. | YT52S00001P1 | [1] | SENSOR,50°C to 120°C | KOBTHERMO |
| 13. | YW02P01005D1 | [1] | SHIM | KOB(1.0) |
| 14. | YW02P01005D2 | [1] | SHIM | KOB(0.6) |
| 16. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBCap |
| 17. | ZW16H10000 | [2] | WASHER | KOB |
